Stainless Steel Wire Rope Thimbles, also known as Stainless Steel Cable Thimble.
Stainless Steel Wire Rope Thimble European Type is manufactured from grade 304 or 316. It has very high corrosion resistant making it a reliable choice for marine, industrial, and architectural applications.
Stainless Steel Wire Rope Thimbles are to prevent wire rope loops from deforming or wearing at the contact point, which helps keep its shape when in use and ensures that the wire rope lasts longer.
Special specifications can also be produced according to drawings and samples.
All the CLGR® wire rope thimble has passed the international industry certification standards, and you can be completely assured of quality.
Brand | CLGR® |
Size wire | 2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 22mm, 24mm, 26mm |
Material | Stainless Steel Grade 304 or 316 |
Surface Treatment | Highly Polished |
Processing | Stamping |
Part No. | Size (mm) | A (mm) | B (mm) | C (mm) | L (mm) | M (mm) | S | Weight (g) |
CRSSWRTEU02 | 2 | 2.1 | 7 | 10 | 11 | 15 | 0.7 | 1 |
CRSSWRTEU03 | 3 | 2.9 | 10 | 14 | 15 | 20 | 1 | 2.3 |
CRSSWRTEU04 | 4 | 3.5 | 11 | 16 | 17 | 24 | 1 | 3.3 |
CRSSWRTEU05 | 5 | 4.5 | 13 | 20 | 21 | 25 | 1 | 5 |
CRSSWRTEU06 | 6 | 5.2 | 16 | 23 | 26 | 29 | 1.2 | 8.5 |
CRSSWRTEU07 | 7 | 6.3 | 18 | 25 | 29 | 38 | 1.2 | 10.6 |
CRSSWRTEU08 | 8 | 8.8 | 20 | 30 | 32 | 44 | 1.5 | 14 |
CRSSWRTEU10 | 10 | 11 | 26 | 39 | 42 | 56 | 2 | 38 |
CRSSWRTEU12 | 12 | 13 | 28 | 42 | 43 | 61 | 2 | 47.5 |
CRSSWRTEU14 | 14 | 15 | 34 | 51 | 58 | 75 | 2 | 71 |
CRSSWRTEU16 | 16 | 17 | 37 | 56 | 60 | 80 | 2.5 | 109 |
CRSSWRTEU18 | 18 | 20 | 42 | 63 | 66 | 87 | 2.5 | 130 |
CRSSWRTEU20 | 20 | 21 | 45 | 68 | 79 | 102 | 3 | 205 |
CRSSWRTEU22 | 22 | 24 | 50 | 77 | 90 | 117 | 3 | 252 |
CRSSWRTEU24 | 24 | 28 | 58 | 85 | 95 | 124 | 4 | 399 |
CRSSWRTEU26 | 26 | 28 | 66 | 97 | 103 | 135 | 4 | 483 |
