CLGR® Galvanized Tubular Thimble without Gusset CRTTG2A Type Painted

Name: CLGR® Galvanized Tubular Thimble without Gusset CRTTG2A Type Painted
Brand: CLGR®

Galvanized Tubular Thimble without Gusset CRTTG2A Type, also known as tube thimble without gusset and Pipe Thimble.

Tubular Thimble is shaped like a tube, with smooth inner walls and an open end.

Wire Rope Tubular Thimble Without Gusset is manufactured from superior carbon steel.

The thimble helps maintain the shape and integrity of the looped end of the wire rope, preventing it from becoming distorted or flattened under load.

It is easy to install, thread the wire rope through the wire rope tube thimble, then place the clamp over the intersection of the wire rope tube thimble and the and tighten the screws of the wire rope clamp.

Special specifications can also be produced according to drawings and samples.

To Get A Quote >

clgr galvanized tubular thimble without gusset crttg2a type painted manufacturers

clgr galvanized tubular thimble without gusset crttg2a type painted suppliers

clgr galvanized tubular thimble without gusset crttg2a type painted factory

Overview of CLGR® Galvanized Tubular Thimble without Gusset CRTTG2A Type Painted

Brand	CLGR®
Size	G210, G212, G215, G217, G219, G222, G225, G228, G230, G235, G240, G245, G250, G255, G260, G265, G270, G275, G285, G295, G2105, G2110, G2120, G2125, G2140
Size wire	10mm, 12mm, 15mm, 17mm, 19mm, 22mm, 25mm, 28mm, 30mm, 35mm, 40mm, 45mm, 50mm, 55mm, 60mm, 65mm, 70mm, 75mm, 88mm, 94mm, 107mm, 112mm, 120mm, 127mm, 140mm
Material	Super Carbon Steel
Surface Treatment	Zinc Plated, Hot Dip Galvanized, Powder Coated
Processing	Machining, Stamping
Applications	For use with wire ropes.

Specifications of CLGR® Galvanized Tubular Thimble without Gusset CRTTG2A Type Painted

Specifications of CLGR® Galvanized Tubular Thimble without Gusset CRTTG2A Type Painted ng

Part No.	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	Rope diameter (mm)	Weight (kg)
CRTTG2A10	10	90	23	16	6	8	0.18
CRTTG2A12	12	90	23	20	8	10	0.24
CRTTG2A15	15	105	27	25	10	12	0.41
CRTTG2A17	17	115	27	25	10	14	0.39
CRTTG2A19	19	120	32	29	12	16	0.60
CRTTG2A22	22	140	35	32	15	18	0.75
CRTTG2A25	25	180	45	37.6	16	22	1.40
CRTTG2A28	28	180	45	42	16	24	1.75
CRTTG2A30	30	195	47	44	18	26	2.2
CRTTG2A35	35	215	60	49	21	32	2.6
CRTTG2A40	40	240	65	54	23	35	2.95
CRTTG2A45	45	260	70	60	27	38	3.85
CRTTG2A50	50	280	75	64	27	44	4.4
CRTTG2A55	55	298	85	69	29	50	5.1
CRTTG2A60	60	300	88	75	30	54	5.9
CRTTG2A65	65	312	88	79	31	56	6.6
CRTTG2A70	70	332	90	84	31.5	60	7.1
CRTTG2A75	75	350	94	90	32	65	8.0
CRTTG2A85	88	450	130	108	45	72	20.1
CRTTG2A95	94	500	150	114	50	80	24.8
CRTTG2A105	107	550	190	127	52	92	30.4
CRTTG2A110	112	600	200	140	70	96	50.4
CRTTG2A120	120	650	220	152	76	104	68.8
CRTTG2A125	127	660	220	159	78	110	70.0
