Stainless Steel Swivel Bow SB Type, also called stainless swivel or trawl swivel.
One end of this stainless steel swivel is small 'd' shaped eye, and the other end is a bow shaped eye. Our stainless steel swivel bow type is manufactured from grade 304 or 316 stainless steel with high-polish, ideal for highly corrosive marine environments like offshore, maritime, and commercial fishing.
All the swivels are tested and come with test certificates.
Avaliable size in 12mm, 16mm, 19mm. Special specifications and marks can be made according to customers' requirements.
| Brand | CLGR® |
Size | 12mm,16mm,19mm |
WLL | 4:1 |
Material | Stainless Steel grade 304 or 316 |
Finish | Highly Polished, Blue Coating |
Processing | Welding |
Type | Swivel Bow Type |
Important Note | *NOT TO BE USED FOR LIFTING* |
.png "drawing-of-clgr-stainless-steel-swivel-bow-sb-type-fishing-trawling-gear")
| Part No. | Dia. | WLL 5:1 | A | B | C | D | E | Weight |
| mm | ton | mm | kg | |||||
| CRSSB12 | 12 | 1.6 | 45 | 44 | 28 | 36 | 156 | 0.43 |
| CRSSB16 | 16 | 2.6 | 62 | 57 | 35 | 41 | 205 | 0.95 |
| CRSSB19 | 19 | 4 | 70 | 68 | 35 | 51 | 230 | 1.5 |
