CLGR® Forged Stainless Steel Chain Swivel FG Type - Trawling Gear & China Supplier

Name: CLGR® Forged Stainless Steel Chain Swivel FG Type - Trawling Gear & China Supplier
Brand: CLGR®

CLGR® Stainless Steel Chain Swivel, also known as mooring swivel or trawling swivel.

Our chain swivel is manufactured from grade AISI 304 or 316 with highly polishing ideals for highly corrosive marine environments, so it usable for fishing or rigging applications.

This chain swivel prevents line twisting in demanding scenarios including offshore trawling net systems, vessel mooring configurations, and aquaculture cage anchoring operations where it maintains smooth rotation under full load conditions.

We can customize different sizes according to customer requirements.

To Get A Quote >

12 CLGR® Forged Stainless Steel Chain Swivel FG Type Trawling Gear & China Supplier

clgr forged stainless steel chain swivel fg type trawling gear china supplier factory

clgr forged stainless steel chain swivel fg type trawling gear china supplier exporter

clgr forged stainless steel chain swivel fg type trawling gear china supplier china

clgr forged stainless steel chain swivel fg type trawling gear china supplier in china

clgr forged stainless steel chain swivel fg type trawling gear china supplier manufacturers

 

Overview of CLGR® Forged Stainless Steel Chain Swivel FG Type

Brand	CLGR®
Size	137.3mm, 183mm
WLL	5:1
Material	Stainless Steel grade 304 /316
Finish	Highly Polished
Processing	Drop Forged
Important Note	NOT TO BE USED FOR LIFTING

Specifications of CLGR® Forged Stainless Steel Chain Swivel FG Type


Part No.	A	B	C	D	E	F	G	H	I	Weight
Part No.	mm
CRSSFG137	137.3	80	52.3	40	16.5	71.25	55	14.3	24.3	0.66
CRSSFG169	169	106	62	45	22	89	62	17	32	1.43
CRSSFG183	183	115	67	48	23.5	96	69	18.3	30	1.815
CRSSFG200	200	124.5	73	51.4	28	102.4	74.7	20	36	2.23
CRSSFG214	214	134	76	55	32	111	80	25	36	3.08

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
