Galvanized SuperLoop Thimble Type K15 is manufactured from superior grade raw material as per international qualitative standards. It a reliable choice for marine, industrial, and architectural applications.
Super Loop Thimble Type K15 is designed to provide basic reinforcement and protection for wire rope loops in low-load applications.
Their purpose is to prevent wire rope loops from deforming or wearing at the contact point, which helps keep its shape when in use and ensures that the wire rope lasts longer.
Special specifications can also be produced according to drawings and samples.
We are a highly professional Chinese manufacturer and supplier of rigging products. If you are interested, please feel free to contact us.
Brand | CLGR® |
Size wire | 2", 2-1/2", 3" |
Material | Super Mild Steel |
Surface Treatment | Hot Dipped Galvanized |
Processing | Forged, Stamping, Welding |
Origin | China |
Part No. | Rope size (Inch) | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | G (mm) | H (mm) | I (mm) | Weight (Kgs) |
CRK15T2 | 2" | 490 | 250 | 280 | 178 | 26 | 56 | 20 | 96 | 20 | 18 |
CRK15T2 - 1/2 | 2 - 1/2" | 490 | 255 | 305 | 180 | 38 | 68 | 20 | 85/105 | 20 | 26 |
CRK15T3 | 3" | 540 | 300 | 300 | 180 | 42 | 85 | 20 | 120 | 20 | 33 |
