CLGR® Oval Link Eyebolts to BS 4278 Table 2

Name: CLGR® Oval Link Eyebolts to BS 4278 Table 2
Brand: CLGR®

CLGR® Oval Link Eyebolts to BS 4278 Table 2 also known as Eyebolt with Oval Link and BS 4278 Eyebolt.

Our Oval Link Eyebolts are manufactured in strict compliance with BS 4278 Table 2 standards, crafted from high-grade steel BS970-080A27 that undergoes hardening and tempering heat treatment for superior strength.

Featuring a 5:1 safety factor where the Minimum Breaking Load equals five times the Safe Working Load, these eyebolts are available in sizes from M8 to M48 with self-color, electro-galvanized, or hot-dip galvanized finishes for corrosion protection.

The unique oval link design provides versatile lifting angles and secure connections, making them ideal for heavy-duty rigging, construction, and industrial lifting applications where maximum safety is required.

To Get A Quote >

CLGR® Oval Link Eyebolts to BS 4278 Table 2

oval link eyebolts to bs 4278 table 2 china supplier

oval link eyebolts to bs 4278 table 2 china china manufacturer

 

Overview of Oval Link Eyebolts to BS 4278 Table 2

Brand	CLGR®
Origin	China
Technical Notes	BS4278 table 2 Forgings: 1984 c
Finish	Self colour / Electric Galvanised / Hot Dip Galvanized
Size	M8, M10, M12, M14, M16, M18, M20, M22, M24, M30, M36, M42, M45, M48
Safety Factor	5:1

Specifications of Oval Link Eyebolts to BS 4278 Table 2

Part No.	Size	Safe Working Load	Diameter Thread	Diameter Link	Link Inside Length	Link Inside Width	Base To Centre Height	Thread Length	Diameter Base	Weight Each
Part No.	Size	Tonnes	a (mm)	b (mm)	c (mm)	d (mm)	e (mm)	f (mm)	g (mm)	kg
CRBS4278T208	M8	0.1	8	13	53	24	20	27	39	0.33
CRBS4278T2010	M10	0.15	10	13	53	24	20	27	39	0.35
CRBS4278T212	M12	0.2	12	13	53	24	20	27	39	0.36
CRBS4278T214	M14	0.3	14	13	53	24	20	27	39	0.37
CRBS4278T216	M16	0.4	16	13	53	24	20	27	39	0.38
CRBS4278T218	M18	0.7	18	13	53	24	20	27	39	0.39
CRBS4278T220	M20	1	20	13	53	24	20	27	39	0.4
CRBS4278T222	M22	1.3	22	15	63	29	23	32	47	0.65
CRBS4278T224	M24	1.6	24	15	63	29	23	32	47	0.66
CRBS4278T230	M30	2.5	30	19	80	37	30	41	60	1.31
CRBS4278T236	M36	4	36	24	102	46	38	52	75	2.69
CRBS4278T242	M42	4.5	42	30	126	58	47	65	94	5.31
CRBS4278T245	M45	5	45	30	126	58	47	65	94	5.35
CRBS4278T248	M48	6.3	48	30	126	58	47	65	94	5.5
