CLGR® Italy Type Galvanized Bow Shackle

Name: CLGR® Italy Type Galvanized Bow Shackle
Brand: CLGR®

CLGR® Italy Type Galvanized Bow Shackle also known as Galvanized Bow Shackle Italy Type, Italy type bow shackle and Quenched and tempered drop forged shackle Italian standard.

Certified to Italian standards, this bow shackle is crafted from superior carbon steel and precision-engineered through drop forging, quenching, and tempering for exceptional strength and durability in demanding lifting and rigging applications.

Featuring a secure screw pin design, it is available in hot-dip galvanized, powder-coated, or zinc-plated finishes to provide superior corrosion resistance for marine, construction, and offshore environments.

Ideal for heavy-duty lifting, industrial rigging, and maritime use, this shackle combines reliable performance with versatile load handling capabilities.

Available in sizes ranging from 5mm to 50mm, with custom specifications and markings offered to meet unique project requirements.

To Get A Quote >

Overview of Italy Type Galvanized Bow Shackle

Brand	CLGR®
Origin	China
Technical Notes	Bow shackle conforms to Italy Type
Processing	Forged / Quenched and Tempered
Finish	Galvanized, Powder Coating, or Self Colored
Size	5mm, 6mm, 8mm, 10mm, 11mm, 12mm, 14mm, 16mm, 20mm, 22mm, 25mm, 28mm, 32mm, 36mm, 45mm, 50mm anchor shackle screw pin
Note	Working Load Limit Permanently Shown on Every Shackle.

Specifications of Italy Type Galvanized Bow Shackle

drawing-of-italy-type-galvanized-bow-shackle-china-supplier

Part No.	Size	A	B	C	E	F	D	G	S.W.L.	Weight
Part No.	mm								Kg
CRITBS05	5	10	20	16	19	5	5	11	80	0.017
CRITBS06	6	13	25	20	25	6	6	14	100	0.031
CRITBS08	8	16	32	24	32	8	8	18	200	0.067
CRITBS10	10	19	39	32	41	10	10	20	300	0.123
CRITBS11	11	22	44	35	44	11	11	24	400	0.165
CRITBS12	12	25	49	38	51	12	12	28	500	0.230
CRITBS14	14	28	56	44	59	14	14	30	600	0.360
CRITBS16	16	32	64	50	68	16	16	32	800	0.560
CRITBS20	20	38	78	66	80	20	20	40	1100	1.100
CRITBS22	22	44	88	74	92	22	22	50	1500	1.520
CRITBS25	25	51	95	75	104	25	25	47	2000	2.200
CRITBS28	28	57	113	94	115	28	28	68	2600	3.270
CRITBS32	32	64	128	104	127	32	32	73	3200	4.500
CRITBS36	36	72	144	115	144	36	36	80	4200	7.500
CRITBS45	45	90	180	150	180	45	45	98	7000	12.800
CRITBS50	50	102	202	156	200	50	50	108	8000	18.000
