CLGR® Grade 80 Alloy Bolt Type Anchor Shackle

Name: CLGR® Grade 80 Alloy Bolt Type Anchor Shackle
Brand: CLGR®

CLGR® Grade 80 Alloy Bolt Type Anchor Shackle also known as Lifting shackle, steel shackle, G80 Safety pin bow shackle and Hot dip galvanized Grade 80 alloy anchor shackle with bolt pin for heavy lifting.

Certified to Federal Specification RR-C-271F Type IVA, Grade B, Class 3,SS-EN-13889+A1-2008., this Grade 80 alloy steel anchor shackle is engineered for superior strength and safety in heavy-duty lifting, rigging, and marine applications.

Featuring a 5:1 safety factor and a bolt-type pin design, it ensures secure, reliable connections under extreme loads.

The shackle is drop-forged, quenched, and tempered for maximum durability, with a hot-dip galvanized body and powder-coated pin providing exceptional corrosion resistance.

Available size in 5/16", 3/8", 7/16", 1/2", 5/8", 3/4", 7/8", 1", 1-1/8", 1-1/4", 1-3/8", 1-1/2", 1-3/4", 2". Custom specifications and markings are supported to meet project requirements.

To Get A Quote >

 

Overview of Grade 80 Alloy Bolt Type Anchor Shackle

Brand	CLGR®
Origin	China
Grade	Grade 80
Technical Notes	Meets or exceeds all requirements of ASME B30.26, Federal Specification RR-C-271, & ASTM A148M.
Safety Factor	5: 1
Material	Superior Alloy Steel
Processing	Drop Forged / Quenched and Tempered
Finish	Body: Hot Dipped Galvanized Pin: Powder Coated
Size	5/16”, 3/8”, 7/16”, 1/2”, 5/8”, 3/4”, 7/8”, 1”, 1-1/8”, 1-1/4”, 1-3/8”, 1-1/2”, 1-3/4”, 2”
Tips	Special specification and marks can be made according to customers' requirements

Specifications of Grade 80 Alloy Bolt Type Anchor Shackle

drawing-clgr-of-grade-80-alloy-bolt-type-anchor-shackle

Part No.	Size	WLL/T	B.L/T	A±1.5	C±1.5	D±1	L±3	N	L1±3	B	N.W./LBS
8CRASBP5/16	5/16″	1.2	6	13.5	21.3	8	53	9.5	50.5	8.4	0.22
8CRASBP3/8	3/8″	1.6	8	16.8	25.9	9.7	63.2	11	62	10.8	0.33
8CRASBP7/16	7/16″	2.5	12.5	19	29.5	11.2	74	13	70	12.8	0.49
8CRASBP1/2	1/2″	3.3	16.5	20.6	33.3	12.7	83.3	16	79.5	14.8	1.01
8CRASBP5/8	5/8″	5	25	27	42.9	17.5	106.4	19	101.5	18	1.6
8CRASBP3/4	3/4″	7	35	32	50.8	20.6	126.2	22	117.5	19.4	2.42
8CRASBP7/8	7/8″	9.5	47.5	36.6	57.9	24.6	148	25	136	21.5	3.95
8CRASBP1/1	1″	12.5	62.5	43	68.3	27	166.6	28	153.5	23.8	5.66
8CRASBP1-1/8	1-1/8″	15	75	46	74	31.75	190	32	171.5	25.6	8.27
8CRASBP1-1/4	1-1/4″	18	90	51.6	82.5	35	210	35	192	31	11.71
8CRASBP1-3/8	1-3/8″	21	105	57	92	36	232.7	38	202	33.4	15.83
8CRASBP1-1/2	1-1/2″	30	150	60.5	98	41	254	42	222	34	20.8
8CRASBP1-3/4	1-3/4″	40	200	73.2	126	57.2	313.7	51	278	38	33.91
8CRASBP2/1	2″	55	275	82.5	146	61	347.5	57	307	45	52.25
