CLGR® Commercial Bow Shackle with Screw Pin

Name: CLGR® Commercial Bow Shackle with Screw Pin
Brand: CLGR®

CLGR® Commercial Bow Shackle with Screw Pin also known as bow shackle with screw collar pin European type, Screw pin bow shackle and Galvanized European type bow shackle screw pin for industrial use.

Forged from superior mild steel with a stamped screw pin, this commercial-grade bow shackle offers reliable performance for general-purpose applications.

Available in galvanized, electrophoretic coating, or self-color finishes to suit various environmental conditions.

Ideal for construction, marine, and industrial tying, lashing, and light lifting tasks.

Sizes avaliable in M5, M6, M8, M10, M11, M12, M16, M20, M22, M25, M28, M32, M38, M45, M50. Custom specifications and markings available upon request.

To Get A Quote >

clgr® commercial bow shackle with screw pin

clgr® commercial bow shackle with screw pin china manufacturer

clgr® commercial bow shackle with screw pin china supplier

clgr commercial bow shackle with screw pin european type china manufacturer sale

commercial bow shackle with screw pin european type china supplier

clgr commercial bow shackle with screw pin european type

 

Overview of Commercial Bow Shackle with Screw Pin

Brand	CLGR®
Origin	China
Technical Notes	European Type
Material	Superior mild Steel
Processing	Body: Forged Screw Pin: Stamping
Finish	Galvanized / Electrophoretic Coating / Self-color
Size	M5, M6, M8, M10, M11, M12, M16, M20, M22, M25, M28, M32, M38, M45, M50
Tips	Special specification and marks can be made according to customers' requirements

Specifications of Commercial Bow Shackle with Screw Pin

drawing-of-clgr-commercial-bow-shackle-with-screw-pin

Part No.	D	d	a	c	r	b	S.W.L.	WT/100 pcs
Part No.	mm						Kg	Kg
CR-BS+S-EU-05	5	5	10	19	8	11	80	2.2
CR-BS+S-EU-06	6	6	13	25	10	14	100	4
CR-BS+S-EU-08	8	8	16	32	12	18	200	8
CR-BS+S-EU-10	10	10	19	38	16	20	320	15
CR-BS+S-EU-11	11	11	22	44	18	23	400	20
CR-BS+S-EU-12	12	12	25	51	19	26	520	30
CR-BS+S-EU-16	16	16	32	64	28	33	800	58
CR-BS+S-EU-20	20	20	38	76	33	40	1100	92
CR-BS+S-EU-22	22	22	44	89	37	50	1500	149
CR-BS+S-EU-25	25	25	51	100	40	57	2100	230
CR-BS+S-EU-28	28	28	57	115	47	68	3000	357
CR-BS+S-EU-32	32	32	64	127	52	73	3500	495
CR-BS+S-EU-38	38	38	76	152	63	85	5000	805
CR-BS+S-EU-45	45	45	90	180	75	96	7000	1,438
CR-BS+S-EU-50	50	50	102	200	78	108	8000	2,012
