CLGR® Stainless Steel Bow Shackle Captive Square Head Pin, also called Anchor Shackle Captive Square Head Pin.
Stainless Steel Bow Shackle Captive Square Head Pin is made from 304 or 316 stainless steel for corrosion prevention, ideal for saltwater environment.
The Captive Square Head Pin is fixed design to prevent the pin from getting lost, even in high-vibration or dynamic load conditions. The pin stays connected to the body when fully open, avoiding the chance of dropping into water. And the surface is highly polished, processing is forging and stamping. It offers maximum corrosion resistance and is an excellent accessory for a variety of applications, often used in the marine industry.
Stainless Steel Bow Shackle Captive Square Head Pin is available in multiple sizes: 8mm, 10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 22mm, 25mm. Special specifications and marks can be made according to customers’requirements.
| Brand | CLGR® |
| Size | 8mm, 10mm, 12mm, 14mm, 16mm, 18mm, 20mm, 22mm, 25mm |
| Material | Stainless steel 304 or 316 |
| Surface Finish | Forged, Stamping |
| Processing | Highly Polishing, Electrophoretic Coating |
| Important Note | Not suitable for lifting applications |
| Part No. | Size | A | B | C | D | E | WLL |
| mm | t | ||||||
| CRSSBSCPSHP08 | 8 | 32 | 16 | 16 | 8 | 24 | 200 |
| CRSSBSCPSHP10 | 10 | 38 | 20 | 20 | 10 | 28 | 320 |
| CRSSBSCPSHP12 | 12 | 48 | 24 | 24 | 12 | 36 | 520 |
| CRSSBSCPSHP14 | 14 | 50 | 28 | 28 | 14 | 38 | 700 |
| CRSSBSCPSHP16 | 16 | 55 | 32 | 32 | 16 | 10 | 800 |
| CRSSBSCPSHP18 | 18 | 62 | 36 | 36 | 18 | 43 | 990 |
| CRSSBSCPSHP20 | 20 | 68 | 40 | 40 | 20 | 46 | 1100 |
| CRSSBSCPSHP22 | 22 | 82 | 44 | 44 | 22 | 56 | 1500 |
| CRSSBSCPSHP25 | 25 | 95 | 50 | 50 | 25 | 68 | 2100 |
