CLGR® Galvanized Closed Body Rigging Screw Jaw & Jaw Turnbuckle

Name: CLGR® Galvanized Closed Body Rigging Screw Jaw & Jaw Turnbuckle
Brand: CLGR®

CLGR® Galvanized Closed Body Rigging Screw Jaw & Jaw Turnbuckle, also known as Closed Body Rigging Screw Fork to Fork Turnbuckle, Pipe Turnbuckle Jaw and Jaw, Strainer Screws and Bottle Screws.

Available with a closed body which is suitable for weight loading. Choice of Eye and/or Jaw end fitting and available in a variety of lengths to meet fine adjustment requirements.

Commercial Strainer Screws are not suitable for lifting but are used for bracing and have a choice of eye and/ or hook end fitting. It can be used in lifting and connecting, wire rope fittings, chain fittings, marine hardware fitting.

Our range of pipe turnbuckle fork & fork is available in standard M6, M8, M10, M12, M16, M20, M22, M24, M28, M32, M36, M38, M45, M50, of course special specifications and marks also can be made according to customers' requirements.

To Get A Quote >

CLGR® Closed Body Rigging Screw Jaw & Jaw Turnbuckle

Overview of CLGR® Galvanized Closed Body Rigging Screw Jaw & Jaw Turnbuckle

Brand	CLGR®
Material	Body: Cold-drawn Seamless Steel tube C1020 Jaw: C1045/C1020
Size	M6 M8 M10 M12 M16 M20 M22 M24 M28 M32 M36 M38 M45 M50
Safe Factor	Proof Load is 2.5 times Working Load Limit. Ultimate Load is 5 times the Working Load Limit
Processing	Quenched and Tempered
Finish	Hot Dip Galvanized / Electric Galvanized / Self-Colored
Important Notes	Straight or in-line pull only

Specifications of CLGR® Galvanized Closed Body Rigging Screw Jaw & Jaw Turnbuckle


Part No.	Size	SWL	A	B	C	JAW					Unit Weight
			Screw Dia. (mm)	Length of Body (mm)	Body Dia. (mm)	Hole Dia.	Pin Dia.	Inside		Thickness
						Hole Dia.	Pin Dia.	Length	Width	Thickness
		Tons				G(mm)	D(mm)	F(mm)	E(mm)	H(mm)	kgs
CR-CBT-JJ-06	M6	0.1	6	102	12	3	5	15	7	6	0.11
CR-CBT-JJ-08	M8	0.15	8	110	15	4	6	16	9	6	0.23
CR-CBT-JJ-10	M10	0.375	10	152	21	5	8	21	11	8	0.28
CR-CBT-JJ-12	M12	0.5	12	175	27	6	10	25	13	9	0.8
CR-CBT-JJ-16	M16	0.75	16	229	27	10	12	40	18	9	1.4
CR-CBT-JJ-20	M20	1.2	20	229	33	12	16	45	20	11	2
CR-CBT-JJ-22	M22	1.6	22	305	33	15	18	48	24	13	3.5
CR-CBT-JJ-24	M24	2	24	325	42	16	22	65	28	14	4
CR-CBT-JJ-28	M28	2.8	28	356	48	18	22	59	30	14	4.5
CR-CBT-JJ-32	M32	3.75	32	381	48	20	27	62	34	18	6.5
CR-CBT-JJ-36	M36	4.25	36	381	60	22	28	68	38	18	8
CR-CBT-JJ-38	M38	5	38	406	60	24	33	74	42	20	11
CR-CBT-JJ-45	M45	7.2	45	406	70	24	35.5	110	50	22	*
CR-CBT-JJ-50	M50	10	50	406	76	26	40.5	120	55	24	*
