CLGR® Galvanized Jaw and Jaw Turnbuckle US Type

Name: CLGR® Galvanized Jaw and Jaw Turnbuckle US Type
Brand: CLGR®

CLGR® Galvanized Jaw and Jaw Turnbuckle US Type, also known as Galvanised Rigging Screws- Jaw/Jaw, Turnbuckle Wire Tensioner Strainer Jaw to Jaw, Open Body Rope Rigging Screw and Turnbuckle Straining Screw Jaw and Jaw, are hot dip galvanized for durability and weather resistance.

The jaw-to-jaw design of these turnbuckles makes them particularly useful for applications requiring secure, adjustable connections with opening/closing attachment points. The dual jaw fittings provide a strong, stable link that's easy to install and adjust, ideal for setups needing frequent reconfiguration. This design excels in scenarios like rigging/lifting operations, tensioning support structures, and marine applications where components must fasten securely yet release easily.

To Get A Quote >

8 CLGR® Galvanized Jaw and Jaw Turnbuckle US Type

 

Overview of CLGR® Galvanized Jaw and Jaw Turnbuckle US Type

Brand	CLGR®
Type	US Federal Specification
Material	Superior Carbon Steel
Safety Factor	Proof tested to 2 x WLL and Minimum Break Force is 5 x WLL.
Processing	Drop Forged + Machining + Quenched and Tempered
Finish	Electric Galvanized / Hot Dipped Galvanized
Thread Dia & Take Up(in)	1/4"×4", 5/16"×4 1/2", 3/8"×6", 1/2"×6", 1/2"×9", 1/2"×12" 5/8"×6", 5/8"×9", 5/8"×12", 3/4"×6", 3/4"×9", 3/4"×12" 3/4"×18", 7/8"×12", 7/8"×18", 1"×6", 1"×12", 1"×18" 1"×24", 1 1/4"×12",1 1/4"×18", 1 1/4"×24", 1 1/2"×12" 1 1/2"×18", 1 1/2"×24", 1 3/4"×18", 1 3/4"×24", 2"×24" 2 1/2"×24", 2 3/4"×24"
Note	Turnbuckles recommended for straight or in-line pull only.

Specifications of CLGR® Galvanized Jaw and Jaw Turnbuckle US Type


Part No.	Thread Dia & Take Up(in)	W.L.L. lbs	U.W lbs/pc	Dimension
				B	E	G	J	K	M	N
				B	Closed	G	Open	Closed	Open	Closed
CRTBJJUS01	1/4×4	500	0.37	0.45	1.66	0.64	11.19	7.19	12.18	8.18
CRTBJJUS02	5/16×4 1/2	800	0.56	0.5	2.02	0.87	13.07	8.57	14.12	9.62
CRTBJJUS03	3/8×6	1200	0.85	0.53	2.11	0.85	16.25	10.25	17.5	11.5
CRTBJJUS04	1/2×6	2200	1.82	0.64	3.22	1.07	18.65	12.65	20.14	14.14
CRTBJJUS05	1/2×9	2200	2.29	0.64	3.2	1.07	24.94	15.94	26.43	17.43
CRTBJJUS06	1/2×12	2200	2.71	0.64	3.2	1.07	30.94	18.94	32.43	20.43
CRTBJJUS07	5/8×6	3500	3.21	0.79	3.9	1.32	19.74	13.74	21.82	15.82
CRTBJJUS08	5/8×9	3500	3.95	0.79	3.89	1.32	26.08	17.08	28.16	19.16
CRTBJJUS09	5/8×12	3500	4.58	0.79	3.89	1.32	32.08	20.08	34.16	22.16
CRTBJJUS10	3/4×6	5200	4.8	0.97	4.71	1.52	21.09	15.09	23.68	17.68
CRTBJJUS11	3/4×9	5200	5.85	0.97	4.68	1.52	27.49	18.49	30.08	21.08
CRTBJJUS12	3/4×12	5200	6.72	0.97	4.68	1.52	33.49	21.49	36.08	24.08
CRTBJJUS13	3/4×18	5200	8.45	0.97	4.71	1.52	45.49	27.49	48.08	30.08
CRTBJJUS14	7/8×12	7200	9.37	1.16	5.5	1.77	34.65	22.65	37.62	25.62
CRTBJJUS15	7/8×18	7200	11.8	1.16	5.5	1.77	47.12	29.12	50.09	32.09
CRTBJJUS16	1×6	10000	10.4	1.34	6.09	2.05	23.82	17.82	27.18	21.18
CRTBJJUS17	1×12	10000	13.8	1.34	6.09	2.05	35.82	23.82	39.18	27.18
CRTBJJUS18	1×18	10000	17.1	1.34	6.09	2.05	47.82	29.82	51.18	33.18
CRTBJJUS19	1×24	10000	21	1.34	6.06	2.05	60.42	36.42	63.78	39.78
CRTBJJUS20	1 1/4×12	15200	21.9	1.84	8.09	2.82	39.37	27.37	43.58	31.58
CRTBJJUS21	1 1/4×18	15200	25.9	1.84	8.09	2.82	51.37	33.37	55.58	37.58
CRTBJJUS22	1 1/4×24	15200	29.8	1.84	8.09	2.82	63.93	39.93	68.14	44.14
CRTBJJUS23	1 1/2×12	21400	32.6	2.06	8.93	2.81	40.76	28.76	45.68	33.68
CRTBJJUS24	1 1/2×18	21400	38	2.06	8.93	2.81	52.76	34.76	57.68	39.68
CRTBJJUS25	1 1/2×24	21400	43.5	2.06	8.93	2.81	65.38	41.38	70.3	46.3
CRTBJJUS26	1 3/4×18	28000	53.5	2.6	9.36	3.35	53.35	35.35	59.16	41.16
CRTBJJUS27	1 3/4×24	28000	61.1	2.6	9.36	3.35	65.35	41.35	71.16	47.16
CRTBJJUS28	2×24	37000	96.3	2.62	11.8	3.74	69.64	45.64	76.72	52.72
CRTBJJUS29	2 1/2×24	60000	167	3.06	13.26	4.44	72.97	48.97	82.18	58.18
CRTBJJUS30	2 3/4×24	75000	199	3.69	14.92	4.19	74.75	50.75	85.5	61.5

Note: This item cannot be returned due to safety risks associated with used materials.
