CLGR® DIN764 Medium Link Chain Galvanized - The China Manufacturer Supplier, Factory

Name: CLGR® DIN764 Medium Link Chain Galvanized - The China Manufacturer Supplier, Factory
Brand: CLGR®

CLGR® DIN764 Medium Link Chain Galvanized, is a welded medium chain. From us, one of the leading link chain manufacturers, DIN764 Medium Link Chain Galvanized is suitable for all general uses such as engineering, industrial, agricultural, fishing and marine applications in conjunction with our accessories, ideal for agricultural use and anchoring chains.

CLGR® has sizes ranging from 2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 16mm, 18mm, 19mm, 20mm, 23mm, 26mm, 28mm, 30mm, 33mm.

Remember not to use for overhead lifting!

To Get A Quote >

7 CLGR® DIN764 Medium Link Chain Galvanized

CLGR® DIN764 Medium Link Chain Galvanized - The China Manufacturer Supplier, Factory

Overview of CLGR® DIN764 Medium Link Chain Galvanized

Brand	CLGR®
Size	2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 16mm, 18mm, 19mm, 20mm, 23mm, 26mm, 28mm, 30mm, 33mm
Material	Superior mild Steel
Standard	DIN 764
Processing	Welded
Surface Finish	Self-Color or Electric Galvanized or Hot Dip Galvanized
Note	NOT FOR OVERLOAD LIFTING

Specifications of CLGR® DIN764 Medium Link Chain Galvanized

Part No.	Size		Inside Length			Inside Width	Outside Width	Length Per 11 Links			Weight Per M


	MM	+/-MM	MM	+MM	-MM	MM	MM	MM	+MM	-MM	KG
CR764C02	2	0.2	12	0.2	0.2	3.5	7.5	132	1	0.5	0.07
CR764C03	3	0.2	16	0.2	0.2	4.2	11	176	1.4	0.7	0.16
CR764C04	4	0.2	16	0.3	0.2	5	14	176	1.6	0.9	0.31
CR764C05	5	0.2	18	0.4	0.2	7	18.2	198	1.8	1	0.51
CR764C06	6	0.2	21	0.5	0.2	8	21.5	231	2	1.1	0.74
CR764C08	8	0.2	28	0.4	0.2	11	29	308	2.2	1.2	1.3
CR764C10	10	0.3	35	0.5	0.3	14	36	385	2.7	1.5	2
CR764C12	12	0.3	42	0.6	0.3	16	41	462	3.2	1.8	3
CR764C13	13	0.4	45	0.6	0.3	18	47	495	3.5	2	3.5
CR764C14	14	0.45	49	0.7	0.4	20	48	539	3.8	2	4.1
CR764C16	16	0.5	56	0.8	0.4	22	58	616	4.3	2.5	5.2
CR764C18	18	0.8	63	0.8	0.4	24	65	693	4.7	2.8	6.5
CR764C20	20	1	70	1	0.5	27	72	770	5.4	3.2	8.2
CR764C23	23	1.2	80	1.1	0.5	31	83	880	6.2	3.5	11
CR764C26	26	1.3	91	1.2	0.6	35	94	1001	7	4	14
CR764C28	28	1.4	98	1.3	0.65	36	101	1078	7.5	4.3	16.5
CR764C30	30	1.5	105	1.4	0.7	39	108	1156	7.8	4.6	19
CR764C33	33	1.7	115	1.5	0.75	43	119	1265	8.5	4.9	23
