CLGR® DIN 766 Short Link Chain Galvanized - The China Supplier, Factory

Name: CLGR® DIN 766 Short Link Chain Galvanized - The China Supplier, Factory
Brand: CLGR®

CLGR® DIN 766 Galvanized Short Link Chain, hot dip galvanized and calibrated to DIN 766 international standard. This precision manufacturing aligns with the quality benchmarks set by professional lifting chain manufacturers.

This CLGR® DIN 766 Galvanized Short Link Chain can be used for fishing, mooring and many other uses.

Our anchor chains come in various sizes: 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 16mm, 18mm, 19mm, 20mm, 23mm, 26mm, 28mm, 30mm and 32mm.

Please email CLGR® if you need product advice, have any questions or looking to buy a large quantity or different variation.

To Get A Quote >

6 CLGR® DIN 766 Short Link Chain Galvanized

CLGR® DIN 766 Short Link Chain Galvanized - The China Supplier, Factory

Overview of CLGR® DIN 766 Short Link Chain Galvanized

Brand	CLGR®
Size	5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 16mm, 18mm, 19mm, 20mm, 23mm, 26mm, 28mm, 30mm, 32mm
Standard	DIN 766
Material	Superior Mild Steel
Processing	Welded + Deburring
Surface Finish	Zinc Plated / Electrophoretic Coating / Hot dip galvanized
Note	NOT FOR OVERLOAD LIFTING
Application	Lifting and connecting, Wire rope fittings, Chain fittings

Specifications of CLGR® DIN 766 Short Link Chain Galvanized

Part No.	Size		Inside Length			Inside Width	Outside Width	Length Per 11Links			Weight Per M


	MM	+/-MM	MM	+MM	-MM	MM	MM	MM	+MM	-MM	KG
CRGSLC766C02	2	0.2	12	0.2	0.2	3.5	7.5	132	1	0.5	0.07
CRGSLC766C03	3	0.2	16	0.2	0.2	4.2	11	176	1.4	0.7	0.16
CRGSLC766C04	4	0.2	16	0.3	0.2	5	13.7	176	2.1	1.1	0.32
CRGSLC766C05	5	0.2	18.5	0.4	0.2	6	17	203.5	2.4	1.2	0.5
CRGSLC766C06	6	0.2	18.5	0.4	0.2	7.2	20.2	203.5	2.4	1.2	0.8
CRGSLC766C07	7	0.3	22	0.4	0.2	8.4	23.8	242	3	1.4	1.1
CRGSLC766C08	8	0.3	24	0.4	0.2	9.6	27.2	264	3.2	1.5	1.4
CRGSLC766C09	9	0.4	27	0.5	0.3	10.8	30.6	297	3.6	1.8	1.8
CRGSLC766C10	10	0.4	28	0.5	0.3	12	34	308	3.7	1.9	2.2
CRGSLC766C11	11	0.4	31	0.5	0.3	13.2	37.4	341	4	2	2.7
CRGSLC766C12	12	0.3	36	0.6	0.3	14.4	40.8	396	4.4	2.2	3.1
CRGSLC766C13	13	0.5	36	0.6	0.3	15.6	44.2	396	4.6	2.4	3.8
CRGSLC766C14	14	0.6	41	0.7	0.4	16.8	47.6	451	5.4	2.7	4.4
CRGSLC766C16	16	0.6	45	0.8	0.4	19.2	54.4	495	6	3	5.7
CRGSLC766C18	18	0.9	50	0.8	0.4	21.6	61.2	550	6.6	3.3	7.3
CRGSLC766C19	19	0.4	53	0.9	0.4	22.8	64.6	583	7	3.7	7.97
CRGSLC766C20	20	1	56	1	0.5	24	68	616	7.4	3.7	9
CRGSLC766C23	23	1.2	64	1.1	0.5	27.6	78.2	704	8.4	4.2	12
CRGSLC766C26	26	1.3	73	1.2	0.6	31.2	88.4	803	9.6	4.8	15
CRGSLC766C28	28	1.4	78	1.3	0.65	33.8	95.2	858	10.2	5.1	18
CRGSLC766C30	30	1.5	84	1.4	0.7	41	102	924	11	5.5	19.5
CRGSLC766C32	32	1.6	90	1.5	0.75	43	108.8	990	11.8	5.9	23

FAQs – DIN 766 Galvanised Short Link Chain

1. What is DIN 766 short link chain?

DIN 766 is a German standard that defines the dimensions and technical requirements for short link round steel chains. These chains are characterized by a relatively short link length (pitch) compared to the chain diameter, giving them higher strength and making them suitable for applications like anchoring, mooring, and general industrial securing.

2. What is the difference between DIN 766 and other DIN chain standards (DIN 763, DIN 764)?

The key difference lies in the link length (pitch) relative to the chain diameter:

DIN 766: Short link chain (shortest pitch, highest strength per diameter)
DIN 764: Medium link chain
DIN 763: Long link chain

DIN 766 chains are specifically designed for applications where compactness and strength are critical, such as anchoring systems.

3. What does "short link" mean and why does it matter?

"Short link" refers to chains where the inner link length (pitch) is relatively short – typically about 3–4 times the chain diameter. For example, a 10mm DIN 766 chain has a pitch of 28mm.

Bulk Photos of CLGR® DIN 766 Short Link Chain Galvanized
