CLGR® G80 Alloy Lifting Chain Short Link EN818-7

Name: CLGR® G80 Alloy Lifting Chain Short Link EN818-7
Brand: CLGR®

This G80 Alloy Lifting Chains EN818 - 7 are crafted from alloy steel that has undergone strict quality control and in - depth material analysis.

The anchor chain for sale feature a durable surface treatment, such as power coating finish, which not only provides excellent corrosion resistance but also adds to their aesthetic appeal.

The CLGR® G80 Alloy Lifting Chain Short Link is ideally designed for a wide range of overhead lifting applications, including those in industrial manufacturing, construction, and logistics.

These chain links for sale can be used in combination with connecting accessories such as hooks, shackles, and connecting links, lifting equipment such as electric hoists, winches, and cranes, as well as auxiliary equipment like anti-twist wire ropes and lifting slings.

To Get A Quote >

CLGR® G80 Alloy Lifting Chain Short Link EN818-7

Overview of CLGR® G80 Alloy Lifting Chain Short Link EN818-7

Brand	CLGR®
Size	3mm, 4mm, 5mm, 5.6mm, 6mm, 6.3mm, 6.5mm, 7mm, 7.1mm, 7.9mm, 8mm, 9mm, 9.5mm, 10mm, 11mm, 11.2mm, 11.5mm, 13mm, 16mm, 22mm
Material	Super Alloy Steel
Standard	European Type (EN818-7)
Safety Factor	4: 1
Processing	Welded
Surface Finish	Powder Coating
Tips	Color Code: Customized according to customers' requirements

Specifications of CLGR® G80 Alloy Lifting Chain Short Link EN818-7

Part No.	Size	Nominal Thickness	Pitch	Width	Weight	Load Capacity	Load Capacity


		w	p	H	Approx.	kg*	kg**
		mm	mm	mm	kg / m	kg*	kg**
8CR8187C01	K3,0×9,0	3,0	9,0	10,4	0,21	140	–
8CR8187C02	K4,0×12,0	4,0	12,0	13,7	0,35	400	500
8CR8187C03	K5,0×15,0	5,0	15,0	16,9	0,54	630	750
8CR8187C04	K5,6×17,0	5,6	17,0	18,9	0,68	800	1000
8CR8187C05	K6,0×18,0	6,0	18,0	20,2	0,80	900	1120
8CR8187C06	K6,0×18,5	6,0	18,5	20,2	0,80	900	1120
8CR8187C07	K6,3×19,0	6,3	19,0	21,4	0,86	1000	1200
8CR8187C08	K6,3×19,1	6,3	19,1	21,4	0,86	1000	1200
8CR8187C09	K6,5×18,5	6,5	18,5	21,8	0,94	1100	1300
8CR8187C10	K6,5×19,5	6,5	19,5	21,8	0,92	1100	1300
8CR8187C11	K7,0×21,0	7,0	21,0	23,6	1,10	1250	1500
8CR8187C12	K7,0×22,0	7,0	22,0	23,6	1,10	1250	1500
8CR8187C13	K7,1×20,2	7,1	20,2	23,6	1,10	1250	1500
8CR8187C14	K7,1×21,2	7,1	21,2	23,9	1,10	1250	1500
8CR8187C15	K7,9×21,8	7,9	21,8	27,0	1,40	1600	2000
8CR8187C16	K7,9×23,0	7,9	23,0	27,0	1,40	1600	2000
8CR8187C17	K8,0×22,0	8,0	22,0	27,0	1,40	1600	2000
8CR8187C18	K8,0×24,0	8,0	24,0	27,0	1,40	1600	2000
