CLGR® DIN764 Medium Link Chain Stainless Steel - The China Supplier, Factory

Name: CLGR® DIN764 Medium Link Chain Stainless Steel - The China Supplier, Factory
Brand: CLGR®

CLGR® DIN764 Medium Link Chain, made of stainless steel, excellent for areas of extreme corrosion, such as a saltwater environment, is a kind of welded link chain. Designed and dimensioned according to DIN 764, this high-quality stainless steel short link chain is perfect for use in exterior and corrosive environments, and can be purchased in multiples of 1 meter. As a leading name among link chain manufacturers, CLGR® ensures each chain meets rigorous standards for performance and safety in demanding applications.

Our anchor chains come in various sizes: 5mm, 6mm, 7mm, 8mm, 10mm, 12mm, 13mm, 16mm, 18mm, 20mm, 23mm, 26mm, 30mm, 33mm and 36mm.

Please email CLGR® if you need product advice, have any questions or looking to buy a large quantity or different variation.

To Get A Quote >

CLGR® DIN764 Medium Link Chain Stainless Steel - The China Supplier, Factory

Overview of CLGR® DIN764 Medium Link Chain Stainless Steel

Brand	CLGR®
Size	4mm, 5mm, 6mm, 8mm, 10mm, 13mm, 16mm, 18mm, 20mm, 23mm, 26mm, 30mm, 33mm, 36mm
Material	Stainless Steel 304/316
Standard	DIN 764
Processing	Welded
Surface Finish	Highly Polishing
Note	NOT FOR OVERLOAD LIFTING

Specifications of CLGR® DIN764 Medium Link Chain Stainless Steel

Part No.	Size	Inside Length	Inside Width	Outside Width	Length Per 11 Links	Weight/100M	Breaking Strength
	Size	Inside Length	Inside Width	Outside Width	Length Per 11 Links	Weight/100M	Breaking Strength
	MM	MM	MM	MM	MM	KG	KN
CRSS764C01	4	16	5	14	176	31.3	7
CRSS764C02	5	18	7	18.2	198	51.4	11.8
CRSS764C03	6	21	8	21.5	231	74	16.5
CRSS764C04	8	28	11	29	308	131.5	32
CRSS764C05	10	35	14	36	385	200	50
CRSS764C06	13	45	18	47	495	350	80
CRSS764C07	16	56	22	58	616	520	125
CRSS764C08	18	63	24	65	693	650	160
CRSS764C09	20	70	27	72	770	820	200
CRSS764C10	23	80	31	83	880	1100	250
CRSS764C11	26	91	35	94	1001	1400	320
CRSS764C12	30	105	39	108	1155	1850	415
CRSS764C13	33	115	43	119	1265	2250	500
CRSS764C14	36	126	47	130	1386	2700
