CLGR® DIN 766 Calibrated Anchor Chain Galvanized

Name: CLGR® DIN 766 Calibrated Anchor Chain Galvanized
Brand: CLGR®

CLGR® DIN 766 Galvanized Calibrated Anchor Chain, hot dip galvanized and calibrated to DIN 766 international standard, is commonly used for electric anchor winches and specifically designed for anchoring applications. As a calibrated product from leading link chain manufacturers, these chain links for sale are also ideally suited for fisheries, where it can be used in trawling systems, mooring setups for fishing vessels, and as a robust component in offshore aquaculture installations, ensuring reliable performance in harsh marine environments.

CLGR® DIN 766 Galvanized Calibrated Anchor Chain comes in various sizes: 5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm.

Please email CLGR® if you need product advice, have any questions or looking to buy a large quantity or different variation.

To Get A Quote >

CLGR® DIN 766 Calibrated Anchor Chain Galvanized

Overview of CLGR® DIN 766 Calibrated Anchor Chain Galvanized

Brand	CLGR®
Size	5mm, 6mm, 7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm
Standard	DIN 766 Calibrated
Material	Superior Mild Steel
Processing	Welded + Deburring
Surface Finish	Zinc Plated / Electrophoretic Coating
Note	NOT FOR OVERLOAD LIFTING
Application	Lifting and connecting, Wire rope fittings, Chain fittings

Specifications of CLGR® DIN 766 Calibrated Anchor Chain Galvanized

Part No.	Size		Inside Length			Inside Width		Length Per 11 Links			Working Load	Test Force	Min. Breaking Force


	D	TOL	L	TOL		Min. b	Max. B	11 L	TOL
	mm		mm			mm		mm
CR766GCA05	4	±0.2	16	0.3	-0.2	4.8	13.6	176	0.8	-0.4	200	5	8
CR766GCA06	5	±0.2	18.5	0.4	-0.2	6	17	204	0.9	-0.5	320	8	12.5
CR766GCA07	6	±0.2	18.5	0.4	-0.2	7.2	20.4	204	0.9	-0.5	400	10	16
CR766GCA08	7	±0.3	22	0.4	-0.2	8.4	23.8	242	1.1	-0.5	630	16	25
CR766GCA09	8	±0.3	24	0.4	-0.2	9.6	27.2	264	1.2	-0.6	800	20	32
CR766GCA10	9	±0.4	27	0.5	-0.3	10.8	30.6	297	1.3	-0.7	1,000	25	40
CR766GCA11	10	±0.4	28	0.5	-0.3	12	36	308	1.4	-0.7	1,250	32	50
CR766GCA12	11	±0.4	31	0.5	-0.3	13.2	40	341	1.5	-0.8	1,600	40	63
CR766GCA13	13	±0.5	36	0.6	-0.3	15.6	47	396	1.7	-0.9	2,000	50	80
CR766GCA14	14	±0.6	41	0.7	-0.4	16.8	50	451	2	-1	2,500	63	100
CR766GCA16	16	±0.6	45	0.8	-0.4	19.2	58	495	2.2	-1.1	3,200	80	125
CR766GCA18	18	±0.9	50	0.8	-0.4	21.6	65	550	2.5	-1.2	4,000	100	160
CR766GCA20	20	±1.0	56	1	-0.5	24	72	616	2.8	-1.4	5,000	125	200
CR766GCA23	23	±1.2	64	1.1	-0.5	27.6	83	704	3.2	-1.6	6,300	160	250
CR766GCA26	26	±1.3	73	1.2	-0.6	31.2	94	803	3.6	-1.8	8,000	200	320
CR766GCA28	28	±1.4	78	1.3	-0.6	33.6	101	858	3.8	-2	10,000	250	400
CR766GCA30	30	±1.5	84	1.4	-0.7	36	108	924	4.2	-2.1	11,200	280	450
CR766GCA32	32	±1.6	90	1.5	-0.7	38.4	115	990	4.5	-2.2	12,500	320	500
CR766GCA36	36	±1.8	101	1.7	-0.8	43.2	130	1,111	5	-2.5	16,000	400	630
CR766GCA40	40	±2.0	112	1.9	-0.8	48	144	1,232	5.6	-2.8	20,000	500	800
CR766GCA42	42	±2.1	118	2	-1	50	151	1,298	5.8	-3	22,400	560	900
