CLGR® Chain Shackle Square Head Pin European Type for Trawling

Name: CLGR® Chain Shackle Square Head Pin European Type for Trawling
Brand: CLGR®

CLGR® Chain Shackle Square Head Pin European Type for Trawling, also called straight shackle, D/Dee shackle or trawl shackle.

D shackle with square head pin, made from superior mild steel, and Surface Finished self-colored. Chain Shackle comes with handy square head pin which you can fasten the pin by hand.

The square head pin design of the shackles for sale ensures secure connections for trawl gear, fishing nets, chains, and rigging systems while preventing rope tangling. The shackles for sale are ideal for offshore operations, commercial fishing, and heavy-duty marine applications

CLGR® Chain Shackle is available in a range of sizes, including 5mm, 6mm, 8mm, 9mm, 10mm, 12mm, 14mm, 16mm, 19mm, 22mm, 25mm. Special specifications and marks can be made according to customers' requirements.

To Get A Quote >

3 CLGR® Chain Shackle Square Head Pin European Type for Trawling

CLGR® Chain Shackle Square Head Pin European Type for Trawling

 

Overview of CLGR® Chain Shackle Square Head Pin European Type for Trawling

Brand	CLGR®
Size	5mm, 6mm, 8mm, 9mm, 10mm, 12mm, 14mm, 16mm, 19mm, 22mm, 25mm
Standard	European Type
Material	Superior Mild Steel
Surface Finish	Self-Colored, Zinc Plated, Hot Dipped Galvanized.
Processing	Forged
Important Note	Not suitable for lifting applications

Specification of CLGR® Chain Shackle Square Head Pin European Type for Trawling

trawling-clgr-d-shackle-square-head-pin-self-colored-european-type

Part No.	Size	d	L	L1	B	B1	D	Thread dia.	Unit Weight	Work Load Limit
Part No.	mm	mm	mm	mm	mm	mm	mm	mm	g	kg
CRSHDS01	5	5	28.75	18.5	20	10	10.5	M5	15	70
CRSHDS02	6	6	38	26	25	13	12	M6	26	140
CRSHDS03	8	8	50	34	33	17	17	M8	63	220
CRSHDSO4	9	9	54	36	36	18	18	W3/8	83	270
CRSHDS05	10	10	57.5	38	38	18	19	M10	108	320
CRSHDS06	12	12	71	47	49	25	24	M12	195	400
CRSHDS07	14	14	91	63	56	28	28	M14	323	600
CRSHDS08	16	16	92.5	61	64	32	31	M16	450	900
CRSHDS09	19	19	112	73.5	76	38	39	M20	766	1,100
CRSHDS10	22	22	130	86	88	44	44	M22	1,181	1,600
CRSHDS11	25	25	145	95.5	100	50	49	M24	1,690	2,200
