CLGR® G100 Cradle Eye Grab Hook

Name: CLGR® G100 Cradle Eye Grab Hook
Brand: CLGR®

CLGR® Cradle Eye Grab Hook, also known as Eye Shortening Grab Hook grade 100 with Wings, Lifting Eye Shortening Grab Hook and G100 Eye Shortening Grab Hook.

Eye grab hook is used for shortening chain legs of a sling. The grab hook is attached to the master link with the same connection link as the chain.

The eye grab hook, which features support lugs with no reduction to the working load limits, is attached to the master link with the same connection link as the chain. Eye grab hooks, equipped with these support lugs maintaining full working load limits, are used for lifting heavy loads, most commonly in commercial shipping and haulage industries.

To Get A Quote >

CLGR® G100 Cradle Eye Grab Hook China Factory

CLGR® G100 Cradle Eye Grab Hook China Supplier

CLGR® G100 Cradle Eye Grab Hook China Manufacturer

 

Overview of CLGR® G100 Cradle Eye Grab Hook

Brand	CLGR®
Standard	EN1677
Material	Super Alloy Steel
Safety Factor	4: 1
Processing	Body: Forged / Quenched and Tempered
Finish	Body: Powder Coated
Size	6mm, 8mm, 10mm, 13mm, 16mm, 20mm, 22mm
Tips	Color Code: Customized according to customers’ requirements
Note	Never exceed working load limit. Use Only Grade 100 Attachments For Overhead Lifting

Specifications of CLGR® G100 Cradle Eye Grab Hook

drawing-clgr®-g100-cradle-eye-grab-hook-china-supplier

Part No.	Size (mm)	W.L.L (tons)	E (mm)	B (mm)	D (mm)	M (mm)	L (mm)	N.W. (kgs)
10CREGH06	6	1.4	8	14.5	30.5	43.5	71	0.2
10CREGH08	8	2.5	10.8	18	37	53	91.5	0.28
10CREGH10	10	4	13.5	22.5	48.5	72	127.5	0.72
10CREGH13	13	6.7	16.5	28	59	96	163	1.6
10CREGH16	16	10	19.2	36	74	112.5	183	2.45
10CREGH20	20	16	24	43.5	89.5	143	227	4.72
10CREGH22	22	19	27	48.5	100.5	160.5	260.5	8.2
