CLGR® Grade 100 Enlarged Master Link Assembly, also known as G100 Enlarged Master Link w/ Sub Assembly, Quad Master Link Assemblies, Master Link Multi, Oblong Master Link with large size Sub-Links, Oblong Master Link Sub Assembly, Multi-leg master link.
The Grade 100 Enlarged Master Link with Sub assembly is designed for complex chain sling configurations requiring multiple connection points. Its extra-wide primary master link ensures a secure fit on large crane hooks, while the enlarged subassemblies provide ample space for multiple fittings without crowding.
This Grade 100 Enlarged Master Link Assembly is well-suited for use with chain, wire rope, and synthetic slings.
Every component, including subassemblies, is individually proof tested, certified, and carries full traceability for guaranteed safety and compliance.
Brand | CLGR® |
Standard | EN1677-4 |
Material | Super Alloy Steel |
Safety Factor | Ultimate load is 4 times the Working Load Limit |
Processing | Main Link: Forged SubLink: Welded Quenched and Tempered Pressing flat only on request |
Finish | Powder Coated |
Size(Master link-Assembly) | 19-14mm, 22-17mm, 30-22mm, 40-25mm, 50-32mm |
Tips | Color Code : Customized according to customers' requirements |
Part No. | WEIGHT | WLL | B.L | DIMENSION(MM) | |||||
A | B | D | a | b | d | ||||
10CRMLAOS06 | 1.8 | 3.5 | 14 | 150±5 | 90±4 | 19±1.5 | 120±5 | 70±4 | 14±1.5 |
10CRMLAOS08 | 3 | 5 | 20 | 160±5 | 95±4 | 22±1.5 | 140±5 | 80±4 | 17±1.5 |
10CRMLAOS10 | 6.5 | 11.5 | 46 | 200±5 | 120±5 | 30±1.5 | 160±5 | 95±4 | 22±1.5 |
10CRMLAOS13 | 15 | 17 | 68 | 250±6 | 150±5 | 40±2 | 190±5 | 110±5 | 25±1.5 |
10CRMLAOS16 | 23 | 28 | 112 | 300±6 | 200±5 | 50±2 | 200±5 | 120±5 | 32±2 |
