CLGR® G100 / Grade 100 Cradle Clevis Grab Hook

Name: CLGR® G100 / Grade 100 Cradle Clevis Grab Hook
Brand: CLGR®

CLGR® G100 Cradle Clevis Grab Hook, also known as G100 Clevis Shortening Grab Hook, Lifting Clevis Grab Hook, Clevis Shortening Grab Hook W/ Wings.

Forged from alloy steel, the Cradle Clevis Grab Hook delivers 25% greater strength than Grade 80 equivalents and serves as an efficient chain shortener for sling assemblies. They are attached to the master link via a clevis attachment, offering the flexibility to shorten chain slings and enabling back - hooking.

These grab hooks are designed with supporting lugs, ensuring that there is no reduction in the working load limit. The clevis itself is engineered for the easy connection of chain.

Commonly used in construction and engineering, material handling, transport and logistics, and industrial manufacturing.

To Get A Quote >

CLGR® G100 Grade 100 Cradle Clevis Grab Hook

CLGR® G100 Grade 100 Cradle Clevis Grab Hook China Supplier

CLGR® G100 Grade 100 Cradle Clevis Grab Hook China Manufacturer

CLGR® G100 Grade 100 Cradle Clevis Grab Hook China

CLGR® G100 Grade 100 Cradle Clevis Grab Hook china wholesale

 

Overview of CLGR® G100 / Grade 100 Cradle Clevis Grab Hook

Brand	CLGR®
Standard	EN1677
Material	Super Alloy Steel
Safety Factor	4: 1
Processing	Body: Forged / Quenched and Tempered
Finish	Body: Powder Coated
Size	6mm, 8mm, 10mm, 13mm, 16mm, 20mm, 22mm
Tips	Special specifications and marks can be customized
Note	Use Only Grade 100 Attachments For Overhead Lifting

Specifications of CLGR® G100 / Grade 100 Cradle Clevis Grab Hook

drawing-of-clgr®-g100-/-grade-100-cradle-clevis-grab-hook-china-supplier

Part No.	Weight (kg)	W.L.L. 4:1 (t)	B.L. (t)	A±0.5	B±1.5	E±1	M±2	L±2
10CRCGH06	0.22	1.4	5.6	7.5	32	8	43.5	75
10CRCGH08	0.34	2.5	10	9.5	36	10.8	53	91.5
10CRCGH10	0.82	4	16	12	46	13.5	72	126
10CRCGH13	1.75	6.7	26.8	15	59	16.5	96	163.5
10CRCGH16	2.88	10	40	17.5	70	19.2	112.5	183.5
10CRCGH20	4.84	16	64	24	85	24	143	224
10CRCGH22	8.3	19	76	27	100	27	160.5	262
