CLGR® Eye Slip Hook with Latch Grade 43 High Test

Name: CLGR® Eye Slip Hook with Latch Grade 43 High Test
Brand: CLGR®

CLGR® Eye Slip Hook with Latch Grade 43 High Test also known as High test slip hook with spring latch, Grade 43 carbon steel slip hook and Hot dipped galvanized G43 eye slip hook with spring latch for heavy towing.

Certified to U.S. Federal Specification, this heavy-duty eye slip hook is drop forged from superior carbon steel and undergoes quenching and tempering heat treatment, delivering a 4:1 safety factor for demanding industrial applications.

Integrated spring-loaded safety latch prevents accidental release during dynamic operations, and its wide throat enables easy connection to shackles, eyes and chains. Multiple finishes (powder coated, hot-dipped galvanized, electric galvanized, or self-color) for the hook body and Dacroment/stainless steel for the latch ensure strong corrosion resistance, ideal for construction, marine and industrial use.

Available in sizes from 1/4" to 1/2" , this Grade 43 eye slip hook combines robust construction with operational security.

Custom finishes, markings, and sizes can be provided to meet specific project requirements.

Note: This product is not rated for overhead lifting applications.

To Get A Quote >

eye slip hook with latch grade 43 high test

eye slip hook with latch grade 43 high test china

eye slip hook with latch grade 43 high test clgr rigging hook

eye slip hook with latch grade 43 high test china manufacturer

eye slip hook with latch grade 43 high test supplier

 

Overview of Eye Slip Hook with Latch Grade 43 High Test

Brand	CLGR®
Origin	China
Technical Notes	Eye slip hook conform to U.S. Federal Specification
Material	Superior Carbon Steel
Safety Factor	4: 1
Processing	Body: Drop Forged / Quenched and Tempered Latch: Stamping
Finish	Body: Powder Coated / Hot Dipped Galvanized / Electric Galvanized / Self-Color Latch: Dacroment / Stainless steel
Size	1/4”, 5/16”, 3/8”, 7/16”, 1/2” Eye Slip Hook
Tips	Customized according to customers’ requirements

Specifications of Eye Slip Hook with Latch Grade 43 High Test

drawing-clgr-of-eye-slip-hook-with-latch-grade-43-high-test

Part No.	Size	WEIGHT	WLL	A±0.3	D±0.5	R±1	E±1	L±1
Part No.	Size	lbs	lbs	A±0.3	D±0.5	R±1	E±1	L±1
CR-43-ESH+L-1/4	1/4″	0.22	2600	8.5	13	65.5	18.5	93
CR-43-ESH+L-5/16	5/16″	0.3	3900	9	16	74	24.5	107
CR-43-ESH+L-3/8	3/8″	0.67	5400	10.25	18	86.5	32.5	123.8
CR-43-ESH+L-7/16	7/16″	0.71	7200	12.7	20.6	98.8	32	142.5
CR-43-ESH+L-1/2	1/2″	0.95	9200	14.5	23	109.5	41.5	156
