CLGR® G80 Wide Body Shackle with Bolt Pin

Name: CLGR® G80 Wide Body Shackle with Bolt Pin
Brand: CLGR®

CLGR® G80 Wide Body Shackle with Bolt Pin, also known as Wide Body Sling Saver, Wide Body Sling Shackle.

It is a high-strength lifting component designed for heavy-duty rigging and chain applications. Manufactured from Grade 80 alloy steel, it offers superior load capacity and wear resistance compared to standard carbon steel shackles.

The wide body design provides a larger opening, making it easier to connect thick chains, wire ropes, and large fittings. The bolt pin with nut and split pin ensures a secure, tamper-resistant connection that won't accidentally loosen under vibration or dynamic loads.

Finished with a durable powder coating or galvanized surface, this shackle resists corrosion in outdoor and marine environments. Each unit is proof-tested and marked with its working load limit (WLL) and grade for full traceability.

Ideal for lifting, towing, mooring, and chain sling assemblies in construction, offshore, and industrial applications.

Available in a range of sizes to suit different chain diameters and load requirements. Custom configurations available upon request.

To Get A Quote >

Overview of CLGR® G80 Wide Body Shackle with Bolt Pin

Brand	CLGR®
Origin	China
Safety Factor	4: 1
Material	Superior Forged Alloy Steel – Quenched and Tempered
Processing	Forged & 100% magnaflux crack detection
Finish	Body: Hot Dipped Galvanized Pin: Hot Dipped Galvanized/Powder Coating
Size	WLL 18T, 30T, 40T, 55T, 75T, 125T, 150T, 200T, 250T, 300T, 400T, 500T

Specification of CLGR® G80 Wide Body Shackle with Bolt Pin

Drawing of CLGR® G80 Wide Body Shackle with Bolt Pin

Part No.	WLL	A	B	C	D	E	F	G	H	I	Weight (KG)
Part No.	WLL	A	B	C	D	E	F	G	H	I	Weight (KG)
CR8WSBP18	18	180	30	69	147	52	64	102	239	35	7
CR8WSBP30	30	200	35	90	165	69	79	126	279	42	13
CR8WSBP40	40	235	45	109	199	84	97	140	331	51	21
CR8WSBP55	55	270	55	115	240	90	100	160	389	57	30
CR8WSBP75	75	317	54	125	290	110	120	185	473	70	48
CR8WSBP125	125	390	85	154	366	137	150	220	583	80	92
CR8WSBP150	150	434	89	179	391	147	170	253	645	95	140
CR8WSBP200	200	482	100	199	481	158	205	280	759	105	205
CR8WSBP250	250	530	110	227	542	179	240	300	859	120	264
CR8WSBP300	300	620	122	245	601	195	265	350	947	134	360
CR8WSBP400	400	690	145	293	576	231	320	370	985	160	580
CR8WSBP500	500	790	160	328	681	263	339	450	1131	180	780
CR8WSBP600	600	865	170	348	741	289	370	490	1234	200	980
CR8WSBP700	700	901	190	392	751	315	400	540	1284	215	1360
CR8WSBP800	800	947	200	420	851	342	420	554	1426	230	1430
CR8WSBP900	900	1023	220	466	851	368	440	580	1488	255	1650
CR8WSBP1000	1000	1107	240	490	851	399	460	614	1532	270	2120
CR8WSBP1250	1250	1182	260	510	931	452	530	650	1666	300	3700
CR8WSBP1500	1500	1253	280	550	950	483	560	680	1710	320	4000
