CLGR® Stainless Steel Four Prong Grapnel Anchor

Name: CLGR® Stainless Steel Four Prong Grapnel Anchor
Brand: CLGR®

The Stainless Steel Four Prong Grapnel Anchor, commonly called Fixed Grapnel Anchor.

This Stainless Steel Four Prong Grapnel Anchor is made from 316 marine-grade stainless steel, and is designed for rock and reef setting.

Welded in one piece for extra strength, the grapnel is small and light, and is also ideal for retrieving rope lines or items that have fallen overboard.

To Get A Quote >

CLGR® Stainless Steel Four Prong Grapnel Anchor Company

Overview of CLGR® Stainless Steel Four Prong Grapnel Anchor

Brand	CLGR®
Material	Stainless Steel AISI316
Type	Stainless Steel Four Prong Grapnel Anchor
Surface Finish	Mirror Polished
Origin	China

Specifications of CLGR® Stainless Steel Four Prong Grapnel Anchor

Part No.	Size	Height (MM)	Width (MM)	Shank Dia (MM)
CRSSFPG02	2KG	368	290	22
CRSSFPG03	3KG	570	380	25
CRSSFPG05	5KG	595	430	25
CRSSFPG07	7KG	660	465	28
CRSSFPG09	9KG	700	570	30
CRSSFPG12	12KG	730	540	36
CRSSFPG16	16KG	770	650	39
CRSSFPG18	18KG	895	730	40
CRSSFPG20	20KG	860	670	45
