CLGR® Stainless Steel Anchor Shackle with Screw Pin, also known as Bow Shackle Screw Pin.
Anchor Shackle with Screw Pin is made of 304 or 316 stainless steels. This material has glossy surface, antirust, anti-corrosion, sturdy and durable to use. As a part of our premium rigging hardware collection, the shackles for sale are designed to work with hooks, ropes, and other rigging components.
CLGR® Bow Shackle with Screw Pin offers a wide range of applications in various industries, from construction to maritime. Anchor Shackle Screw Pin allows for easy attachment and removal, and the bow design supports multi-directional forces.
As one of the leading shackles manufacturers, we offer sizes from 4mm to 36 mm, also can be made according to customers' requirements.
For matched wire ropes, chains, or other fishing riggings, please visit our product lines.
| Brand | CLGR® |
| Size | 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm 18mm, 20mm, 22mm, 25mm, 28mm, 32mm, 36mm |
| Standard | Bow Shackle European Type |
| Material | Stainless Steel grade 304 or 316 |
| Surface Finish | Highly Polishing, Electrophoretic Coating |
| Processing | Forged, Stamping |
| Important Note | Not suitable for lifting applications |
| Part No. | SIZE | A | B | C | D | E | MBL |
| mm | KN | ||||||
| CR-SS-BS-EU-04 | 4 | 16 | 8 | 8 | 4 | 14 | 5.8 |
| CR-SS-BS-EU-05 | 5 | 19 | 10 | 10 | 5 | 16 | 9.1 |
| CR-SS-BS-EU-06 | 6 | 25 | 12 | 12 | 6 | 20 | 13.2 |
| CR-SS-BS-EU-08 | 8 | 32 | 16 | 16 | 8 | 24 | 23.7 |
| CR-SS-BS-EU-10 | 10 | 38 | 20 | 20 | 10 | 28 | 37.3 |
| CR-SS-BS-EU-12 | 12 | 48 | 24 | 24 | 12 | 36 | 54.9 |
| CR-SS-BS-EU-14 | 14 | 50 | 28 | 28 | 14 | 38 | 74.8 |
| CR-SS-BS-EU-16 | 16 | 55 | 32 | 32 | 16 | 10 | 97.7 |
| CR-SS-BS-EU-18 | 18 | 62 | 36 | 36 | 18 | 43 | 136.1 |
| CR-SS-BS-EU-20 | 20 | 68 | 40 | 40 | 20 | 46 | 184.7 |
| CR-SS-BS-EU-22 | 22 | 82 | 44 | 44 | 22 | 56 | 223.8 |
| CR-SS-BS-EU-25 | 25 | 95 | 50 | 50 | 25 | 68 | - |
| CR-SS-BS-EU-28 | 28 | 108 | 56 | 56 | 28 | 74 | - |
| CR-SS-BS-EU-32 | 32 | 120 | 64 | 64 | 32 | 84 | - |
| CR-SS-BS-EU-36 | 36 | 135 | 72 | 72 | 36 | 92 | - |
FAQS
1. What is the difference between 304 and 316 stainless steel for shackles?
316 stainless steel contains molybdenum, which provides superior corrosion resistance in marine and chloride-rich environments. 304 is suitable for general industrial use, while 316 is recommended for saltwater or coastal applications.
2. Why is this shackle marked "Not suitable for lifting applications"?
This bow shackle is designed for towing, mooring, and static rigging, where loads are steady. Overhead lifting requires shackles with additional design factors and certifications (e.g., Grade 80/100). Always select the right shackle for the intended application.
3. What sizes and MBL capacities do you offer?
Sizes from 4mm to 36mm. The MBL (Minimum Breaking Load) ranges from 5.8 kN for the 4mm size to 353.6 kN for the 32mm size. Full table is provided above.
4. Can I get custom markings or special sizes?
Yes. CLGR® provides customized markings, special sizes, and specific finishes upon request. Please contact our sales team with your requirements.
