CLGR® Lifting Eye Nut DIN 582 Stainless Steel

Name: CLGR® Lifting Eye Nut DIN 582 Stainless Steel
Brand: CLGR®

Designed as a permanent attachment point on equipment such as motors, gearboxes, control cabinets, and other industrial machinery.

Manufactured from AISI 316 stainless steel and marked in accordance with DIN 582, this eye nut offers reliable corrosion resistance and traceability for demanding environments.

When used with double-strand slings, the safe working load applies only when the angle between each sling leg and the vertical does not exceed 45°. Lateral loading or larger angles should be avoided to maintain safe operation.

For proper installation, the eye nut must be fully screwed in until the bearing faces are in firm contact. The mating thread must be of equal length and the base material of matching strength to ensure full load transfer.

To Get A Quote >

Overview of CLGR® Lifting Eye Nut DIN 582 Stainless Steel

Brand	CLGR®
Standard	Eye Nut Conform To DIN582
Material	Type 304 or 316 Stainless Steel
Processing	Precision Cast
Finish	Highly Polishing
Size	M6, M8, M10, M12, M16, M20, M24, M30, M36
Note	Never to be used for overhead lifting
Country of Origin	China

Specification of CLGR® Lifting Eye Nut DIN 582 Stainless Steel

drawing-stainless-steel-din-582-lifting-eye-nut-cast-china-manufacturer

Part No.	D1	D3	H	Min.BL
Part No.	mm			KN
CRA2/4EN58206	M6	16	28	6.2
CRA2/4EN58208	M8	20	33	8.2
CRA2/4EN58210	M10	25	42	13.5
CRA2/4EN58212	M12	30	51	20
CRA2/4EN58216	M16	35	60	41.2
CRA2/4EN58220	M20	40	68.8	70.6
CRA2/4EN58224	M24	50	86.8	105.9
CRA2/4EN58230	M30	60	104.8	188.3
CRA2/4EN58236	M36	70	122.6	270.7

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
