Stainless Steel Lifting Eye Nut JIS 1169 with UNC Thread CLGR®

Name: Stainless Steel Lifting Eye Nut JIS 1169 with UNC Thread CLGR®
Brand: CLGR®

CLGR® Stainless Steel Eye Nut JIS 1169 with UNC Thread, also known as Lifting Eye Nut, JIS B 1169 Eye Nut, Eye Nut for Eye Bolt.

Precision cast from 316 stainless steel with a high-polished finish, this eye nut with UNC thread offers excellent corrosion resistance and durability for demanding marine and industrial environments.

The precision-engineered threading ensures smooth installation, while the secure eye loop design provides a reliable attachment point for rigging hardware, threaded rods, and anchor points.

The eye nut must be completely screwed into the mounting surface to ensure proper load transfer and safe operation.

Ideal for a wide range of applications, including shade structures, wire balustrades, architectural rigging, cable railing systems, sailboats, yachts, and marine installations. Its polished appearance combines strength with aesthetic appeal, making it suitable for both functional and visible installations.

To Get A Quote >

Overview of Stainless Steel Lifting Eye Nut JIS 1169 with UNC Thread

Brand	CLGR®
Standard	Eye Nut Conform To JIS 1169 Standard
Material	Stainless Steel AISI 304 / AISI 316 Eye Nut
Processing	Precision Cast
Finish	Highly Polishing
Size	1/4″, 5/16”, 3/8″, 1/2″, 5/8”, 3/4″, 7/8”, 1″ eye nut
Note	Never to be used for overhead lifting
Country of Origin	China

Specification of Stainless Steel Lifting Eye Nut JIS 1169 with UNC Thread

drawing-of-stainless-steel-lifting-eye-nut-jis-1169-with-unc-thread-china-supplier

Part No.	D1	B	H
CRSS1169UNC1/4	1/4″	0,59	1.14″
CRSS1169UNC5/16	5/16”	0.79	1.52″
CRSS1169UNC3/8	3/8″	0,98	1.87″
CRSS1169UNC1/2	1/2″	1.18	2.36″
CRSS1169UNC5/8	5/8”	1.38	2.76″
CRSS1169UNC3/4	3/4″	1.57	3.35″
CRSS1169UNC7/8	7/8”	1,97	4.17″
CRSS1169UNC1	1″	1.97	4.17″
