CLGR® Stainless Steel Shoulder Eye Bolt UNC Thread With Nut and Washer

Name: CLGR® Stainless Steel Shoulder Eye Bolt UNC Thread With Nut and Washer
Brand: CLGR®

Stainless Steel Shoulder Eye Bolt UNC Thread With Nut and Washer, also known as Collared Eye Bolts or Shoulder Eye Bolts, are supplied complete with nut and washer. They feature UNC coarse threads and are available in diameters from 1/4" to 7/8".

Manufactured from marine-grade stainless steel 304/316, these eye bolts are cast and highly polished to a smooth finish, offering excellent corrosion resistance.

Suitable for both straight-line and angular pulls, they provide reliable performance in a wide range of lifting and rigging applications.

Custom shank lengths are available upon request.

Available thread sizes: 1/4″, 5/16″, 3/8″, 1/2″, 5/8″, 3/4″, 7/8″ shoulder eye bolt.

To Get A Quote >

Overview of Stainless Steel Shoulder Eye Bolt UNC Thread With Nut and Washer

Brand	CLGR®
Material	Stainless Steel 304/316 Long Shank Eye Bolt
Processing	Hot Upsetting
Finish	High Polished
Size	1/4″, 5/16″, 3/8″, 1/2″, 5/8″, 3/4″, 7/8″ shoulder eye bolt
Tips	Including eyebolts, nut and washer.
Notes	Custom length of threads available.
Country of Origin	China

Specification of Stainless Steel Shoulder Eye Bolt UNC Thread With Nut and Washer

drawing-of-stainless-steel-shoulder-eye-bolt-unc-thread-with-nut-and-washer

Part No.	D1	L	D	B	Min.BL
Part No.	D1	L	D	B	lbs
CRSSEBLSUNC01	1/4″	1.57″	0.197″	0.59″	2300
CRSSEBLSUNC02	1/4″	2.00″	0.197″	0.59″	2300
CRSSEBLSUNC03	1/4″	2.36″	0.197″	0.59″	2300
CRSSEBLSUNC04	5/16″	2.36″	0.236″	0.79″	3650
CRSSEBLSUNC05	5/16″	4.00″	0.236″	0.79″	3650
CRSSEBLSUNC06	3/8″	3.15″	0.315″	1.00″	5200
CRSSEBLSUNC07	3/8″	4.00″	0.315″	1.00″	5200
CRSSEBLSUNC08	3/8″	5.00″	0.315″	1.00″	5200
CRSSEBLSUNC09	3/8″	6.00″	0.315″	1.00″	5200
CRSSEBLSUNC10	1/2″	1.57″	0.394″	1.18″	9150
CRSSEBLSUNC11	1/2″	3.15″	0.394″	1.18″	9150
CRSSEBLSUNC12	1/2″	4.00″	0.394″	1.18″	9150
CRSSEBLSUNC13	1/2″	6.00″	0.394″	1.18″	9150
CRSSEBLSUNC14	5/8″	1.77″	0.472″	1.38″	14000
CRSSEBLSUNC15	5/8″	6.00″	0.472″	1.38″	14000
CRSSEBLSUNC16	3/4″	6.00″	0.590″	1.57″	21000
CRSSEBLSUNC17	3/4″	12.00″	0.590″	1.57″	21000
CRSSEBLSUNC18	7/8″	9.00″	0.710″	1.57″	21000
