CLGR® Lifting Eye Bolt DIN 580 Stainless Steel

Name: CLGR® Lifting Eye Bolt DIN 580 Stainless Steel
Brand: CLGR®

CLGR® DIN 580 lifting eye bolt is manufactured from AISI 316 stainless steel (marine grade A4) with a polishing finish.

Designed for lifting and transport activities, this eye bolt is particularly suitable for security-critical areas and high-requirement applications where reliability is essential. The CE marking and clearly indicated Working Load Limit (WLL) provide clear guidance for safe use.

The stated WLL applies to vertical lifts only. For angular lifting applications, the working load must be reduced accordingly. The eye bolt should be fully screwed in, with the bearing face in firm contact with the mating surface to ensure proper load transfer.

Available size: M6, M8, M10, M12, M16, M20, M24, M30, M36 to suit different load requirements.

For custom specifications or further information, please contact us.

To Get A Quote >

Overview of CLGR® Lifting Eye Bolt DIN 580 Stainless Steel

Brand	CLGR®
Standard	To DIN580
Material	Stainless Steel (AISI 304 / AISI 316)
Processing	Precision Cast
Finish	Highly Polishing
Size	M6 , M8 , M10 , M12 , M16 , M20 , M24 , M27 . M30 , M36
Note	Never to be used for overhead lifting

Specifications of CLGR® Lifting Eye Bolt DIN 580 Stainless Steel


Part No.	D1	D3	H	L	Min.BL
Part No.	mm				KN
CRSS580EB06	M6	16	28	11	6.2
CRSS580EB08	M8	20	33	13	8.2
CRSS580EB10	M10	25	42	17	13.5
CRSS580EB12	M12	30	51	20.5	20
CRSS580EB16	M16	35	60	27	41.2
CRSS580EB20	M20	40	68.8	30	70.6
CRSS580EB24	M24	50	86.8	36	105.9
CRSS580EB30	M30	60	104.8	45	188.3
CRSS580EB36	M36	70	122.6	54	270.7
