CLGR® Stainless Steel Eye Bolt Unwelded, also known as Unwelded Eye Bolt, is manufactured from grade 304 / 316 stainless steel for excellent corrosion resistance and long-term durability.
The "unwelded" construction means the eye (loop) is formed from a single piece of solid bar stock with no welded joint. This seamless design eliminates the weak point typically found at weld seams, providing consistent strength around the full circumference of the eye and a cleaner, smoother appearance.
Available in 5mm and 6mm sizes. Ideal for light to medium-duty applications including cable guiding, rope attachment, wire balustrading, and marine rigging where corrosion resistance is essential.
Thread sizes and shank lengths are available upon request.
Brand | CLGR® |
Material | Stainless steel 304 / 316 eye bolt |
Finish | Polished |
Size | M5, M6 stainless steel welded eye bolt |
Tips | Other sizes and custom lengths on request. |
Country of Origin | China |
Part No. | D | L | L1 | D1 |
mm | ||||
CRSSEBUW01 | M5 | 30 | 27 | 8 |
CRSSEBUW02 | M5 | 40 | 37 | 8 |
CRSSEBUW03 | M5 | 50 | 47 | 8 |
CRSSEBUW04 | M6 | 20 | 17 | 10 |
CRSSEBUW05 | M6 | 30 | 27 | 10 |
CRSSEBUW06 | M6 | 40 | 37 | 10 |
CRSSEBUW07 | M6 | 60 | 57 | 10 |
CRSSEBUW08 | M6 | 60 | 57 | 10 |
