CLGR® Grade 70 Weld-on Grab Hooks, also known as G70 Drop Forged Weld-On Heavy Duty Towing Hook, Grade 70 Weld Grab Hook.
Because of their Grade 70 strength, these weld-on hooks are suitable for a wide range of rigging applications, offering reliable and durable performance even under heavy loads.
Constructed from forged steel, these forged hooks are built to withstand wear, abrasion, and corrosion, ensuring long-lasting use in demanding environments.
Designed for permanent installation, these grab hooks can be easily welded onto truck beds, trailers, or other equipment, providing a secure and sturdy attachment point.
Brand | CLGR® |
Technical Notes | U.S. Federal Specification |
Material | Alloy Steel |
Processing | Forged |
Finish | Self-color |
Size-Wire | 5/16”, 3/8”, 5/8” |
Note | NOT FOR OVERHEAD LIFTING |
Part No. | A | B | C | WLL | WT |
(in) | (in) | (in) | (lbs) | (lbs) | |
CR-WoGH-5/16 | 2 | 0.46 | 2-1/2 | 4700 | 0.45 |
CR-WoGH-3/8 | 2-2/5 | 1/2 | 3 | 6600 | 0.81 |
CR-WoGH-5/8 | 4 | 0.9 | 3-4/5 | 15800 | 2.47 |
NOT FOR OVERHEAD LIFTING!
NEVER EXCEED CAPACITY.
DO NOT USE FOR LIFTING PEOPLE OR LOADS OVER PEOPLE.
