CLGR® Grade 100 Forged Alloy Master Link / Ring

Name: CLGR® Grade 100 Forged Alloy Master Link / Ring
Brand: CLGR®

Grade 100 Forged Alloy Master Link / Ring, also known as G100 Enlarged Master Link, G100 Large Oblong Link and G100 Oblong Master Link and Grade 80 Master Rings.

Forged from super alloy steel, it complies with EN1677-4 / DIN5688-3 standards. Heavy duty tested and certified grade 100 master link suitable for single and double leg overhead lifting applications.

And it can be used with G100 chains, chain connectors. With a working load limit ranging from 1.4 t to 81.5 t, it is ideal for heavy-duty lifting applications, offering both strength and reliability.

To Get A Quote >

CLGR® Grade 100 Forged Alloy Master Link-Ring Quality

CLGR® Grade 100 Forged Alloy Master Link-Ring for Sale

CLGR® Grade 100 Forged Alloy Master Link-Ring Material

CLGR® Grade 100 Forged Alloy Master Link-Ring Design

CLGR® Grade 100 Forged Alloy Master Link-Ring Use

CLGR® Grade 100 Forged Alloy Master Link-Ring Price

CLGR® Grade 100 Forged Alloy Master Link-Ring Working Principle

 

Overview of CLGR® Grade 100 Forged Alloy Master Link / Ring

Brand	CLGR®
Size	13mm, 16mm, 18mm, 23mm, 27mm, 33mm, 36mm, 45mm, 50mm
Material	Superior Alloy Steel
Standard	European Type
Safety Factor	4: 1
Processing	10-CR-ML1-13 to 10-CR-ML1-36 ⇒ FORGED (pressing flat on request) 10-CR-ML1-45 to 10-CR-ML1-50 ⇒ FORGED (no pressing flat) Quenched and Tempered
Surface Finish	Powder Coated
Note	Color code can be made according to customers' requirements.

Specifications of CLGR® Grade 100 Forged Alloy Master Link / Ring

Drawing Grade 100 Forged Alloy Master Link / Ring

Part No.	G100 Chain		WEIGHT (KGS)	WLL (T)	DIMENSION(mm)
Part No.	1 LEG SLING	2 LEG SLING	WEIGHT (KGS)	WLL (T)	A	B	C
10-CR-ML1-10	5	5	0.14	1.4	80	50	10
10-CR-ML1-13	6/7	6	0.34	2.3	110	60	13
10-CR-ML1-16	8	7	0.53	3.5	110	60	16
10-CR-ML1-18	10	8	0.86	5	135	75	18
10-CR-ML1-23	13	10	1.6	7.6	160	90	23
10-CR-ML1-27	16	13	2.46	10	180	100	27
10-CR-ML1-33	19	16	4.14	14	200	110	33
10-CR-ML1-36	22	19	6.22	25.1	260	140	36
10-CR-ML1-45	26	22	12.85	30.8	340	180	45
10-CR-ML1-50	32	26	16.22	40	350	190	50
10-CR-ML1-60	-	32	27.01	60	400	200	60
10-CR-ML1-70	-	-	45	81.5	460	250	70

Master Link for single or double leg chain slings.

Ultimate load is 4 times the Working Load Limit.

10-CR-ML1-13 to 10-CR-ML1-36: There will be pressing flat only on request for use with G100 Omega Link.

10-CR-ML1-45 to 10-CR-ML1-50: There is no pressing flat.
