CLGR® Split Links Sister Clips Chrome Steel

Name: CLGR® Split Links Sister Clips Chrome Steel
Brand: CLGR®

CLGR® Split Links Sister Clips Chrome Steel, also known as C Link Connector Links and C Rings Links.

This C-shaped chain connecting link is made of high tensile chrome steel. C-Links are designed for applications where two chains require connecting or they require connection to an end component. These aren't recommended for heavy loads. C Links are typically used in the fishing, education, sports, building and heavy industrial sectors.

For guaranteed reliability, choose the CLGR's Chrome Split Links - your trusted partner in netting solutions.

To Get A Quote >

23 CLGR® Split Links Sister Clips Chrome Steel

CLGR® Split Links Sister Clips Chrome Steel – The China Manufacturer Supplier, Factory Suppliers

CLGR® Split Links Sister Clips Chrome Steel – The China Manufacturer Supplier, Factory Exporter

CLGR® Split Links Sister Clips Chrome Steel – The China Manufacturer Supplier, Factory China

CLGR® Split Links Sister Clips Chrome Steel – The China Manufacturer Supplier, Factory Manufacturers

 

Overview of CLGR® Split Links Sister Clips Chrome Steel

Brand	CLGR®
Material	Chrome Steel
Size	9/16", 5/8", 3/4", 7/8"
Safety Factor	5:1
Processing	Stamping
Surface Finish	Chrome

Specifications of CLGR® Split Links Sister Clips Chrome Steel

Drawing CLGR® Split Links Sister Clips Chrome Steel

Part No.	Size	Dia. mm	WLL 5:1 ton	A mm	B mm	Weight kg/100
CRCLCRM9/16	9/16"	14	0.5	60	18	20
CRCLCRM5/8	5/8"	16	0.7	72	21	33
CRCLCRM3/4	3/4"	19	1.4	80	23	55
CRCLCRM7/8	7/8"	22	1.8	88	27	75

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
