CLGR® G100 Alloy Lifting Chains EN818-2 Short Link Chain - China Supplier

Name: CLGR® G100 Alloy Lifting Chains EN818-2 Short Link Chain - China Supplier
Brand: CLGR®

CLGR® G100 Alloy Lifting Chains EN818-2, also referred to as Grade 10 Alloy Steel Load Chain, G100 Alloy Steel Short Link Chain, or Welded Link Chain, are high-strength welded chains designed for demanding lifting and rigging applications.

These G100 chains are manufactured from alloy steel and are available with either a black oiled finish or a natural (self-colored) finish. They are precisely heat-treated and tempered to deliver superior durability and impact resistance, making them a reliable choice for chain slings, chain slings for lifting, and complete rigging chains systems.

Compared to the same size Grade 80 chain, Grade 100 provides 25% higher lifting capacity. For optimal safety, it is recommended to use Grade 100 chain links and components together as a matched system.

We also offer G80 chain with the same chain sizes (6mm, 7mm, 8mm, 10mm, 13mm, 16mm, 19mm, 22mm, 26mm, 32mm) available for flexible overhead lifting tasks.

Whether you need a lifting chain for hoists, a load chain for rigging, or a complete overhead lifting chain system, CLGR® delivers secure, reliable solutions. Choose the right configuration for your load requirements.

To Get A Quote >

CLGR® G100 Alloy Lifting Chains Short Link, EN818-2 China Supplier

Overview of G100 Alloy Lifting Chains EN818-2

Brand	CLGR®
Size	6mm, 7mm, 8mm, 10mm, 13mm, 16mm, 19mm, 22mm, 26mm, 32mm
Material	Super Alloy Steel
Standard	European Type EN818-2
Safety Factor	4: 1
Processing	Welded
Surface Finish	Black Oiled or Self Colored Powder Coating
Tips	Color Code: Customized according to customers' requirements

Specifications of G100 Alloy Lifting Chains EN818-2

Part No.	Size (mm)	WLL (T)	B. L. (T)	A (mm)	B min (mm)	C max (mm)	Weight/m (KGS)
10CR8182C06	6±0.24	1.4	5.6	18±0.5	8.7	21.6	0.96
10CR8182C07	7±0.28	1.9	7.6	21±0.6	9.5	25.2	1.26
10CR8182C08	8±0.32	2.5	10	24±0.7	11	28.8	1.57
10CR8182C10	10±0.40	4	16	30±0.9	14	36	2.46
10CR8182C13	13±0.52	6.7	26.8	39±1.2	18	46.8	4.18
10CR8182C16	16±0.64	10	40	48±1.4	22	57.6	6.28
10CR8182C19	19±0.90	14	56	57±1.6	27	68.4	8.92
10CR8182C22	22±1.10	19	76	66±2.0	30	79.2	11.88
10CR8182C26	26±1.30	21.2	84.8	78±2.3	35	96.2	16.18
10CR8182C32	32±1.60	31.5	126	96±2.9	43	118	24.1

Bulk Photos of CLGR® G100 Alloy Lifting Chains EN818-2
