CLGR® DIN 766 Short Link Chain Stainless Steel - The China Manufacturer Supplier, Factory

Name: CLGR® DIN 766 Short Link Chain Stainless Steel - The China Manufacturer Supplier, Factory
Brand: CLGR®

CLGR® DIN 766 Short Link Chain, made of stainless steel 316, excellent for areas of extreme corrosion, such as a saltwater environment. Designed and dimensioned according to DIN 766, the high-quality stainless steel short link chains from lifting chain manufacturers are perfect for use in exterior and corrosive environments, and can be purchased in multiples of 1 meter.

CLGR® DIN 766 Short Link Chain in A4, AISI 316 grade, come in various sizes: 2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 18mm,19mm, 20mm, 22mm, 23mm, 26mm, 28mm, 30mm,32mm.

To Get A Quote >

CLGR® DIN 766 Short Link Chain Stainless Steel - The China Manufacturer Supplier, Factory

3 CLGR® DIN 766 Short Link Chain Stainless Steel

 

Overview of CLGR® DIN 766 Short Link Chain Stainless Steel

Brand	CLGR®
Size	2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 10mm, 11mm, 12mm, 13mm, 14mm, 16mm, 18mm, 19mm, 20mm, 22mm, 23mm, 26mm, 28mm, 30mm, 32mm
Standard	DIN 766
Material	Stainless Steel
Processing	Welded
Surface Finish	Highly Polishing
Note	NOT FOR OVERLOAD LIFTING
Application	Lifting and connecting, Wire rope fittings, Chain fittings

Specifications of CLGR® DIN 766 Short Link Chain Stainless Steel

Part No.	Size		Inside Length			Inside Width	Outside Width	Length Per 11links			Weight Per M


	MM	+/-MM	MM	+MM	-MM	MM	MM	MM	+MM	-MM	KG
CRSSSLC76602	2	0.2	12	0.2	0.2	3.5	7.5	132	1	0.5	0.07
CRSSSLC76603	3	0.2	16	0.2	0.2	4.2	11	176	1.4	0.7	0.16
CRSSSLC76604	4	0.2	16	0.3	0.2	5	13.7	176	2.1	1.1	0.32
CRSSSLC76605	5	0.2	18.5	0.4	0.2	6	17	203.5	2.4	1.2	0.5
CRSSSLC76606	6	0.2	18.5	0.4	0.2	7.2	20.2	203.5	2.4	1.2	0.8
CRSSSLC76607	7	0.3	22	0.4	0.2	8.4	23.8	242	3	1.4	1.1
CRSSSLC76608	8	0.3	24	0.4	0.2	9.6	27.2	264	3.2	1.5	1.4
CRSSSLC76609	9	0.4	27	0.5	0.3	10.8	30.6	297	3.6	1.8	1.8
CRSSSLC76610	10	0.4	28	0.5	0.3	12	34	308	3.7	1.9	2.2
CRSSSLC76611	11	0.4	31	0.5	0.3	13.2	37.4	341	4	2	2.7
CRSSSLC76612	12	0.3	36	0.6	0.3	14.4	40.8	396	4.4	2.2	3.1
CRSSSLC76613	13	0.5	36	0.6	0.3	15.6	44.2	396	4.6	2.4	3.8
CRSSSLC76614	14	0.6	41	0.7	0.4	16.8	47.6	451	5.4	2.7	4.4
CRSSSLC76616	16	0.6	45	0.8	0.4	19.2	54.4	495	6	3	5.7
CRSSSLC76618	18	0.9	50	0.8	0.4	21.6	61.2	550	6.6	3.3	7.3
CRSSSLC76619	19	0.4	53	0.9	0.4	22.8	64.6	583	7	3.7	7.97
CRSSSLC76620	20	1	56	1	0.5	24	68	616	7.4	3.7	9
CRSSSLC76622	22	1.1	62	1.1	0.5	26.4	75	682	8	4	11
CRSSSLC76623	23	1.2	64	1.1	0.5	27.6	78.2	704	8.4	4.2	12
CRSSSLC76626	26	1.3	73	1.2	0.6	31.2	88.4	803	9.6	4.8	15
CRSSSLC76628	28	1.4	78	1.3	0.65	33.8	95.2	858	10.2	5.1	18
CRSSSLC76630	30	1.5	84	1.4	0.7	41	102	924	11	5.5	19.5
CRSSSLC76632	32	1.6	90	1.5	0.75	43	108.8	990	11.8	5.9	23

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
