CLGR® Compacted Steel Fishing Wire Rope 6X19S+IWRC for Trawl, also known as Trawl Wire Compact 6x19 Seal+IWRC, some customer also called it Compact Trawl Warp.
This Trawl Wire is durable and long-lasting, the surface finish is galvanized, which provides excellent protection against corrosion. Also available in bright self-colored with lightly greased. Trawl wire ropes are manufactured from premium-grade steel, incorporating a specialized zinc-aluminum coating that ensures exceptional corrosion resistance.
IWRC is formed by twisting steel wires, featuring high tensile strength that enables it to withstand greater pulling force and heavy loads, making it suitable for applications requiring high strength, from hoisting operations and suspension systems to winch lines and beyond.
Utilizing latest engineering techniques, these ropes blend outstanding tensile strength, fatigue resilience, and corrosion protection, achieving a precise equilibrium between long-term durability and operational performance. Their robust construction makes them a reliable choice for both marine trawling and heavy-duty industrial uses, where consistent performance under rigorous conditions is essential.
Brand | CLGR® |
Construction | 6×S(19)+IWRC, also known as 6X19S+IWRC, or 6x19 Seal+IWRC |
Surface Finish | Galvanized |
Type | CRWRFLEX6 Compacted Steel Wire Rope |
Origin | China |
Warning | No Return due to safety risks from used materials |
Part No. | Nominal | Minimum Breaking Load (Metric TON) | Approx. | |||
6xS19+IWRC | ||||||
180 KG/MM² | 200 KG/MM² | 220 KG/MM² | ||||
CRWRFLEX 6 | MM | INCH | 1770 N/MM² | 1960 N/MM² | 2160 N/MM² | KG/M |
CRWRFLEX6i01 | 11.2 | 7/16" | 9.8 | 10.6 | - | 0.57 |
CRWRFLEX6i02 | 12 | 11.3 | 12.1 | - | 0.65 | |
CRWRFLEX6i03 | 12.7 | 1/2" | 12.6 | 13.6 | - | 0.73 |
CRWRFLEX6i04 | 13 | 13.2 | 14.3 | - | 0.76 | |
CRWRFLEX6i05 | 14 | 15.3 | 16.5 | 17.3 | 0.89 | |
CRWRFLEX6i06 | 14.3 | 9/16" | 16.0 | 17.2 | 18.0 | 0.92 |
CRWRFLEX6i07 | 15 | 17.6 | 19.0 | 19.8 | 1.02 | |
CRWRFLEX6i08 | 16 | 5/8" | 20.0 | 21.6 | 22.6 | 1.16 |
CRWRFLEX6i09 | 17.5 | 11/16" | 23.9 | 25.8 | 27.0 | 1.38 |
CRWRFLEX6i010 | 18 | 25.3 | 27.3 | 28.6 | 1.46 | |
CRWRFLEX6i011 | 19 | 3/4" | 28.2 | 30.4 | 31.8 | 1.63 |
CRWRFLEX6i012 | 20 | 31.3 | 33.7 | 35.3 | 1.81 | |
CRWRFLEX6i013 | 21 | 13/16" | 34.5 | 37.2 | 38.9 | 1.99 |
CRWRFLEX6i014 | 22 | 37.8 | 40.8 | 42.7 | 2.19 | |
CRWRFLEX6i015 | 22.2 | 7/8" | 38.6 | 41.7 | 43.5 | 2.23 |
CRWRFLEX6i016 | 24 | 15/16" | 45.0 | 48.6 | 50.8 | 2.60 |
CRWRFLEX6i017 | 25 | 48.8 | 52.7 | 55.1 | 2.83 | |
CRWRFLEX6i018 | 25.4 | 1 “ | 50.4 | 54.4 | 56.9 | 2.92 |
CRWRFLEX6i019 | 26 | 1-1/16" | 52.8 | 57.0 | 59.6 | 3.06 |
CRWRFLEX6i020 | 28 | 61.3 | 66.1 | 69.1 | 3.54 | |
CRWRFLEX6i021 | 28.6 | 1-1/8" | 63.9 | 69.0 | 72.1 | 3.70 |
CRWRFLEX6i022 | 30 | 1-3/16" | 70.3 | 75.9 | 79.3 | 4.07 |
CRWRFLEX6i023 | 31.5 | 1-1/4" | 77.5 | 83.7 | 87.5 | 4.49 |
CRWRFLEX6i024 | 32 | 80.0 | 86.4 | 90.3 | 4.63 | |
CRWRFLEX6i025 | 34 | 90.3 | 97.5 | 101.9 | 5.23 | |
CRWRFLEX6i026 | 35 | 1-3/8" | 95.7 | 103.3 | 108.0 | 5.54 |
CRWRFLEX6i027 | 36 | 101.3 | 109.3 | 114.2 | 5.86 | |
CRWRFLEX6i028 | 38 | 112.8 | 121.8 | 127.3 | 6.53 | |
CRWRFLEX6i029 | 38.1 | 1-1/2" | 113.4 | 122.4 | 127.9 | 6.56 |
CRWRFLEX6i030 | 40 | 125.0 | 134.9 | - | 7.23 | |
CRWRFLEX6i031 | 42 | 137.8 | 148.8 | - | 7.97 | |
CRWRFLEX6i032 | 44 | 151.3 | 163.3 | - | 8.75 | |
CRWRFLEX6i033 | 44.5 | 1-3/4" | 154.4 | 166.0 | - | 8.93 |
CRWRFLEX6i034 | 46 | - | 165.3 | 178.5 | - | 9.56 |
CRWRFLEX6i035 | 48 | - | 180.0 | - | - | 10.41 |
CRWRFLEX6i036 | 50 | - | 195.3 | - | - | 11.30 |
CRWRFLEX6i037 | 50.8 | 2" | 201.3 | - | - | 11.66 |
CRWRFLEX6i038 | 52 | - | 211.3 | - | - | 12.22 |
