CLGR® Fishing Compacted Steel Wire Rope 6X19S+FC, also known as Trawl Wire Compact 6x19 Seal+FC, some customer also called it Compact Trawl Warp.
Trawl wire ropes are crafted from high quality steel and feature a specialized zinc-aluminum coating for superior corrosion protection. Wire rope 6x19 is the perfect general use steel cable and can be used for many applications, including as hoisting rope, suspension cables, winch lines, and more. Engineered with latest technology, these wire ropes integrate exceptional strength, fatigue resistance, and corrosion protection, delivering an optimal balance of durability and performance.
Brand | CLGR® |
Construction | 6×S(19)+FC, also known as 6x19S+FC, or 6x19 Seal+FC |
Surface Finish | Galvanized |
Type | CRWRFLEX6f Compacted Steel Wire Rope |
Origin | China |
Warning | No Return due to safety risks from used materials |
| Part No. | Nominal | Minimum Breaking Load(Metric TON) | Approx. | ||
| 6xS19+FC | |||||
| Dia | 180 KG/MM² | 200 KG/MM² | Weight | ||
| CRWRFLEX 6 | MM | INCH | 1770 N/MM² | 1960 N/MM² | KG/M |
| CRWRFLEX6f01 | 11.2 | 7/16" | 8.7 | 9.1 | 0.51 |
| CRWRFLEX6f02 | 12 | 10.0 | 10.5 | 0.59 | |
| CRWRFLEX6f03 | 12.7 | 1/2" | 11.2 | 11.7 | 0.66 |
| CRWRFLEX6f04 | 13 | 11.7 | 12.3 | 0.69 | |
| CRWRFLEX6f05 | 14 | 13.6 | 14.2 | 0.8 | |
| CRWRFLEX6f06 | 14.3 | 9/16" | 14.2 | 14.9 | 0.83 |
| CRWRFLEX6f07 | 15 | 15.6 | 16.4 | 0.92 | |
| CRWRFLEX6f08 | 16 | 5/8" | 17.8 | 18.6 | 1.04 |
| CRWRFLEX6f09 | 17.5 | 11/16" | 21.2 | 22.3 | 1.25 |
| CRWRFLEX6f010 | 18 | 22.5 | 23.6 | 1.32 | |
| CRWRFLEX6f011 | 19 | 3/4" | 25.0 | 26.2 | 1.47 |
| CRWRFLEX6f012 | 20 | 27.7 | 29.1 | 1.63 | |
| CRWRFLEX6f013 | 21 | 13/16" | 30.6 | 32.1 | 1.8 |
| CRWRFLEX6f014 | 22 | 33.6 | 35.2 | 1.98 | |
| CRWRFLEX6f015 | 22.2 | 7/8" | 34.3 | 35.9 | 2.02 |
| CRWRFLEX6f016 | 24 | 15/16" | 39.9 | 41.9 | 2.35 |
| CRWRFLEX6f017 | 25 | 43.3 | 45.4 | 2.55 | |
| CRWRFLEX6f018 | 25.4 | 1 “ | 44.7 | 46.9 | 2.63 |
| CRWRFLEX6f019 | 26 | 1-1/16" | 46.9 | 49.1 | 2.76 |
| CRWRFLEX6f020 | 28 | 54.4 | 57.0 | 3.2 | |
| CRWRFLEX6f021 | 28.6 | 1-1/8" | 56.7 | 59.5 | 3.34 |
| CRWRFLEX6f022 | 30 | 1-3/16" | 62.4 | 65.4 | 3.67 |
| CRWRFLEX6f023 | 31.5 | 1-1/4" | 68.8 | 72.1 | 4.05 |
| CRWRFLEX6f024 | 32 | 71.0 | 74.4 | 4.18 | |
| CRWRFLEX6f025 | 34 | 80.2 | 84.0 | 4.72 | |
| CRWRFLEX6f026 | 35 | 1-3/8" | 85.0 | 89.0 | 5 |
| CRWRFLEX6f027 | 36 | 89.9 | 94.2 | 5.29 | |
| CRWRFLEX6f028 | 38 | 100.1 | 105.0 | 5.89 | |
| CRWRFLEX6f029 | 38.1 | 1-1/2" | 100.7 | 105.5 | 5.92 |
| CRWRFLEX6f030 | 40 | 111.0 | 116.3 | 6.53 | |
| CRWRFLEX6f031 | 42 | 122.3 | 128.2 | 7.2 | |
| CRWRFLEX6f032 | 44 | 134.3 | 140.7 | 7.9 | |
| CRWRFLEX6f033 | 44.5 | 1-3/4" | 137.0 | 143.6 | 8.06 |
