CLGR® Stainless Steel Eye Bolt with Nut & Washer

Name: CLGR® Stainless Steel Eye Bolt with Nut & Washer
Brand: CLGR®

CLGR® Stainless Steel Eye Bolt with Nut & Washer, also known as Lifting Eye Bolt, and Welded Eye Bolt with Nut & Washer.

Manufactured from marine-grade stainless steel 304 or 316 with a polished finish, these eye bolts offer excellent corrosion resistance in harsh environments including marine, coastal, and outdoor installations. The welded eye construction provides a secure attachment point for cables, ropes, and fittings.

Each bolt is supplied complete with a nut and washers for secure mounting.

Available in metric coarse threads, they are commonly used for shade sail installation, as well as general rigging, tie-downs, and marine fastening applications.

Available in a range of sizes with custom specifications upon request.

To Get A Quote >

Stainless Steel Welded Eye Bolt with Nut & Washer

Stainless Steel Eye Bolt with Nut & Washer China Manufacturer

Stainless Steel Eye Bolt with Nut & Washer China Supplier

Overview of CLGR® Stainless Steel Eye Bolt with Nut & Washer

Brand	CLGR®
Material	Stainless Steel AISI 304 or 316 Welded Eye Bolt
Processing	Welded
Finish	High Polished and Electric Polished.
Size	M6, M8, M10, M12 welded eye bolt
Tips	Fitted with nut and washer.
Notes	Easy installed on to threaded fittings.
Country of Origin	China

Specification of CLGR® Stainless Steel Eye Bolt with Nut & Washer

drawing-stainless-steel-welded-eye-bolt-with-nut-and-washer-factory

Part No.	Size	A	B	C	D	SWL	BL
Part No.	Size	mm				kgs	kgs
CRSSWEB01	M6*60	M6	13	35	60	250	1000
CRSSWEB02	M6*80	M6	13	35	80	250	1000
CRSSWEB03	M6*90	M6	13	35	90	250	1000
CRSSWEB04	M6*100	M6	13	35	100	250	1000
CRSSWEB05	M8*60	M8	16	45	60	450	1800
CRSSWEB06	M8*80	M8	16	45	80	450	1800
CRSSWEB07	M8*100	M8	16	45	100	450	1800
CRSSWEB08	M8*110	M8	16	45	110	450	1800
CRSSWEB09	M8*130	M8	16	45	130	450	1800
CRSSWEB10	M10*80	M10	23	50	80	600	2400
CRSSWEB11	M10*100	M10	23	50	100	600	2400
CRSSWEB12	M10*130	M10	23	50	130	600	2400
CRSSWEB13	M10*150	M10	23	50	150	600	2400
CRSSWEB14	M10*200	M10	23	50	200	600	2400
CRSSWEB15	M12*100	M12	25	60	100	875	3500
CRSSWEB16	M12*150	M12	25	60	150	875	3500
CRSSWEB17	M12*165	M12	25	60	165	875	3500
CRSSWEB18	M12*185	M12	25	60	185	875	3500
CRSSWEB19	M12*200	M12	25	60	200	875	3500
