CLGR® Grade 80 Master Link Rings European Type Bigger Size

Name: CLGR® Grade 80 Master Link Rings European Type Bigger Size
Brand: CLGR®

CLGR® Grade 80 Master Link, Rings European Type Bigger Size, it's a special type, it has bigger length and bigger width.Also known as Grade 80 Oblong Master Link with Flat, G80 Oblong Recessed Master Link and Grade 80 Master Rings. The surface finish is plastics spraying and forged from superior alloy steel.

Heavy duty tested and certified grade 80 master link suitable for single and double leg overhead lifting applications. It can be used with chain connectors and Grade 80 alloy lifting chains.

To Get A Quote >

CLGR® Grade 80 Master Link Rings European Type Bigger Size

CLGR® Grade 80 Master Link Rings European Type Bigger Size China Factory

CLGR® Grade 80 Master Link Rings European Type Bigger Size China

Overview of CLGR® Grade 80 Master Link Rings European Type Bigger Size

Brand	CLGR®
Standard	EN1677
Material	Alloy Steel
Safety Factor	Ultimate load is 4 times the Working Load Limit
Processing	8CRMLE87 to 8CRMLE2622 ⇒ WELDED (pressing flat on request) 8CRMLE3226 to 8CRMLE3632 ⇒ FORGED (no pressing flat) Quenched and Tempered
Finish	Powder Coated
Size	8mm, 10mm, 13mm, 16mm, 20mm, 22mm, 26mm, 32mm, 36mm
Tips	Color Code: Customized according to customers' requirements

Specifications of CLGR® Grade 80 Master Link Rings European Type Bigger Size

drawing-of-clgr-grade-80-master-link-rings-european-type-bigger-size-china-supplier

Part No.	G80 EN818-2 CHAIN		WEIGHT (KG)	WLL(T)	DINSION(MM)
Part No.	FOR 1 LEG	FOR 2 LEGS	WEIGHT (KG)	WLL(T)	A	B	D
8CRMLE87	8	7	0.38	2. 7	120	70	13
8CRMLE108	10	8	0.67	3.5	140	80	16
8CRMLE1310	13	10	1.2	5.5	160	95	20
8CRMLE1613	16	13	2.45	9.4	190	110	26
8CRMLE2016	20	16	4.48	14.2	230	130	32
8CRMLE2220	22	20	7.5	22.3	275	150	38
8CRMLE2622	26	22	12.8	33.5	340	180	45
8CRMLE3226	32	26	16.55	40.8	350	190	50
8CRMLE3632	36	32	23.28	56.8	400	200	56
