CLGR® Grade 80 Clevis Clutch Locking Clutch

Name: CLGR® Grade 80 Clevis Clutch Locking Clutch
Brand: CLGR®

CLGR® Grade 80 Clevis Clutch Locking Clutch, also known as Clevis Shortening Clutch with Safety Pin, G80 Clevis Clutch with Safety Pin, Grade 80 Clevis Pin Lock Grab Clutch.

The Grade 80Clevis Clutch Locking Clutch enables chain sling shortening while maintaining the full working load limit of the sling. The clevis allows easy connection to chain for lifting chain applications.

Not recommended for use as bottom fitting of sling for back-hooking and reeving applications.

Marked with sizes, batch number, grade, batch tested, and test certificates available upon request.

To Get A Quote >

CLGR® Grade80 Clevis Clutch Locking Clutch

CLGR® Grade80 Clevis Clutch Locking Clutch China Supplier

CLGR® Grade80 Clevis Clutch Locking Clutch Supplier

CLGR® Grade80 Clevis Clutch Locking Clutch China Manufacturer

CLGR® Grade80 Clevis Clutch Locking Clutch China Wholesale

 

Overview of CLGR® Grade80 Clevis Clutch Locking Clutch

Brand	CLGR®
Standard	EN1677
Material	Super Alloy Steel
Safety Factor	4: 1
Processing	Drop Forged / Quenched and Tempered
Finish	Powder Coated
Size	6mm, 7/8mm, 10mm, 13mm, 16mm, 20mm, 22mm
Tips	Color Code: Customized according to customers' requirements
Note	Never exceed working load limit
Country of Origin	China

Specification of CLGR® Grade80 Clevis Clutch Locking Clutch

Drawing of CLGR® Grade80 Clevis Clutch Locking Clutch

Part No.	WEIGHT (kg)	WLL (T)	B.L (T)	A±2	B±0.5	C±1	D±0.5	E±0.3	φ±0.3	L±3	M±0.5	N±0.5	S±0.3
8CRCCLCWP06	0.25	1.12	4.48	38	7.5	27	7.5	7.5	7.7	73	27	16	20.9
8CRCCLCWP08	0.41	2	8	50	9.5	33	9.5	9.2	9.2	92	33	23	22.6
8CRCCLCWP10	0.82	3.15	12.6	60	11.5	43	11.5	12	13.3	115	42.2	26	31
8CRCCLCWP13	1.67	5.3	21.2	79	15	55	15	15.5	16.3	149	54	34	38.4
8CRCCLCWP16	3.85	8	32	98	19	70	19	18.5	19.7	184	70	40	49.8

*Ultimate load is 4 times the Working Load Limit.
