CLGR® Grade 8 Swivel Sling Hook with Ball Bearing, also known as Grade 80 Swivel Ball Bearing Self Locking Hook, G80 Eye Swivel Hook with Ball Bearing, Alloy Swivel Ball Bearing Hoist Hook w/ Latch.
Conformed to the European standard EN 1677-2 for sling components, this Grade 8 Swivel Sling Hook with Ball Bearing is forged from alloy steel and undergoes heat treatment with 4:1 safety hook for heavy lifting.
Operating temperature range from -40°C to 120°C (with no reduction in WLL). 360° rotation design prevents breakage caused by the knotting of ropes or chains. It can be widely used for factory lifting, port transportation, construction engineering, lifting equipment.
Brand | CLGR® |
Standard | EN1677-2 |
Bearing | With Bearing |
Material | Super Alloy Steel |
Latch | Forged |
Safety Factor | 4: 1 |
Processing | Forged / Quenched and Tempered. |
Finish | Powder Coated |
Size | 6mm, 7/8mm, 10mm, 13mm, 16mm, 18/20mm, 22mm |
Tips | Color Code: Customized according to customers' requirements |
Note | Use Only Grade 80 Attachments For Overhead Lifting |
Part No. | SIZE(mm) | DIMENSIONS(mm) | W.L.L. (T) | WEIGHT(kg) | |||||
A | B | C | E | H | L | ||||
8CRHSE6 | 6 | 32 | 72.2 | 32.3 | 26 | 19.5 | 165.6 | 1.12 | 0.61 |
8CRHSE78 | 7/8 | 37 | 88.2 | 40.5 | 30.3 | 24.8 | 204.1 | 2 | 1.11 |
8CRHSE10 | 10 | 48 | 105.5 | 45.7 | 33.6 | 28.0 | 248.6 | 2 | 1.11 |
8CRHSE13 | 13 | 57.5 | 133.8 | 60.3 | 40.2 | 39.5 | 308.8 | 5.3 | 3.54 |
8CRHSE16 | 16 | 73.0 | 164.1 | 62.3 | 47.1 | 43.0 | 353.4 | 8.0 | 6.58 |
