CLGR® Grade 80 Master Link Assembly U.S. Standard

Name: CLGR® Grade 80 Master Link Assembly U.S. Standard
Brand: CLGR®

CLGR® Grade 80 Master Link Assembly U.S. Standard, also known as Master Links with Sublinks G80, Oblong Master Link Sub-Assembly, Grade 80 Quad Master Link Assembly, and Welded Master Link Assembly.

Forged from quenched and tempered alloy steel and finished with a powder-coated layer for corrosion protection, these Grade 80 Quad Master Links feature reinforced construction with precision-flattened contact surfaces. This engineered design enables seamless integration with omega links or thimbles, delivering reliable heavy-duty connectivity specifically for 3-leg and 4-leg chain sling assemblies.

Available sizes in 1/2", 11/16", 5/8", 3/4", 7/8", 1, 1-1/8", 1-1/4", 1-1/2", 1-3/4", 2 (customized sharps and sizes also), it maintains a safety factor of 4:1 to ensure reliable performance under heavy loads.

To Get A Quote >

CLGR® Grade 80 Master Link Assembly U.S. Standard

CLGR® Grade 80 Master Link Assembly U.S. Standard China Suppplier

CLGR® Grade 80 Master Link Assembly U.S. Standard China Manufacturer

Overview of CLGR® Grade 80 Master Link Assembly U.S. Standard

Brand	CLGR®
Standard	U.S. Type (ASME B30.26)
Material	Superior Alloy Steel
Safety Factor	For chain sling: Minimum Ultimate Load is 4 times the Working Load Limit For steel rope sling: Minimum Ultimate Load is 5 times the Working Load Limit
processing	8CRWMLAUS1/2 to 8CRWMLAUS7/8 ⇒ Main link: WELDED; Sub links: WELDED. 8CRWMLAUS1-1/8 to 8CRWMLAUS1-3/4 ⇒ Main link: WELDED; Sub links: WELDED. 8CRWMLAUS2/1 ⇒ Main link: FORGED; Sub links: WELDED. Quenched and Tempered
Finish	Powder Coated
Size	1/2", 11/16", 5/8", 3/4", 7/8", 1, 1-1/8", 1-1/4", 1-1/2", 1-3/4", 2
Tips	Color Code: Customized according to customers' requirements
Note	There will be pressing flat only on request. Use Only Grade 80 Attachments For Overhead Lifting
Country of Origin	China

Specifications of CLGR® Grade 80 Master Link Assembly U.S. Standard

drawing-of-clgr-grade-80-master-link-assembly-u.s.-standard-china-supplier

For chain sling: Minimum Ultimate Load is 4 times the Working Load Limit.

For steel rope sling: Minimum Ultimate Load is 5 times the Working Load Limit.

BLUE AREA SIZE: Main link: WELDED Sub links: WELDED

YELLOW AREA SIZE: Main link: FORGED Sub links: WELDED

Part No.

Size

(in)

Weight

(KG)

Chain

WLL
3 or 4
LEG-45°

(T)

WLL

ROPE

(T)

DIMENSION(MM)

8CRWMLAUS1/2

1/2

0.82

7/32

2.36

2.4

100±5

60±5

14±1

85±5

40±3

12±1

6±0.5

8CRWMLAUS11/16

11/16

1.6

1/4

3.15

3.2

160±6

90±5

18±1

100±5

60±5

14±1

7.6±0.5

8CRWMLAUS5/8

5/8

1.6

1/4

3.15

3.2

160±6

90±5

18±1

100±5

60±5

14±1

7.6±0.5

8CRWMLAUS3/4

3/4

1.95

5/16

4.25

4.2

160±6

90±5

20±1

100±5

60±5

14±1

7.6±0.5

8CRWMLAUS7/8

7/8

3.16

3/8

6.7

180±6

100±5

22±1

150±6

70±5

18±1

8.4±0.5

8CRWMLAUS1

5.28

3/8

270±6

140±5

25±1

155±5

80±4

20±0.5

11±0.5

8CRWMLAUS1-1/8

1-1/8

6.75

1/2

11.2

207±7

140±6

28±1/-2

160±6

90±5

22±1

13.5±0.5

8CRWMLAUS1-1/4

1-1/4

9.31

5/8

207±7

140±6

32±1/-2

180±6

100±5

25±1

16.5±0.5

8CRWMLAUS1-1/2

1-1/2

18.4

3/4

23.6

300±7

160±6

40±1/-2

270±7

140±6

31±1/-2

19±0.5

8CRWMLAUS1-3/4

1-3/4

26.6

7/8

31.5

340±4

180±6

45±1/-2

285±7

155±6

36±1/-2

22±0.5

8CRWMLAUS2

42.91

350±10

190±6

51±1/-2

340±10

180±6

45±1/-2

25±0.5
