CLGR® Grade 80 Clevis Swivel Safety Hook Ball Bearing

Name: CLGR® Grade 80 Clevis Swivel Safety Hook Ball Bearing
Brand: CLGR®

Grade 80 Clevis Swivel Safety Hook Ball Bearing, also known as Swivel Clevis Self-Locking Hook, G80 Clevis Swivel Self locking Hook with Bearing, clevis self-lock hook with ball bearing, Safety Hook Swivel Clevis.

Clevis Swivel Safety Hook features swivel eyes (360° rotation) for improved positioning of the hook before the load is lifted. This makes it much simpler to attach wire rope and fiber rope slings, making your assembly process even more efficient.

Clevis Swivel Safety Hook Ball Bearing is used with Grade 80 chain with a safety factor of 4:1.

To Get A Quote >

CLGR® Grade 80 Clevis Swivel Safety Hook Ball Bearing

CLGR® Grade 80 Clevis Swivel Safety Hook Ball Bearing China Supplier

CLGR® Grade 80 Clevis Swivel Safety Hook Ball Bearing China

Overview of Grade 80 Clevis Swivel Safety Hook Ball Bearing

Brand	CLGR®
Standard	EN1677
Material	Super Alloy Steel
Safety Factor	4: 1
Processing	Drop Forged / Quenched and Tempered
Finish	Powder Coated
WLL	1.12T, 2T
Tips	Color Code: Customized according to customers’ requirements
Note	Never exceed working load limit

Specifications of Grade 80 Clevis Swivel Safety Hook Ball Bearing

drawing-clgr-grade-80-clevis-swivel-safety-hook-ball-bearing-china-supplier

Part No.	WEIGHT/KG	WLL/T	B.L./T	T±1.5	B±2	C±2	L±3	E±3
8CRCSSLHB06	0.71	1.12	4.48	34	8	32	183.5	28
8CRCSSLHB7/8	1.3	2	8	46	9.5	37	230	34

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
