CLGR® Grade 80 Clevis Shortening Clutch

Name: CLGR® Grade 80 Clevis Shortening Clutch
Brand: CLGR®

CLGR® Grade 80 Clevis Shortening Clutch, also known as Grade 80 Lifting Clevis Shortening Clutch, Clevis Chain Shortening Clutch, Clevis Chain Clutch with Safety Pin, G80 Clevis Type Shortening Clutch.

Grade 80 Clevis Chain Clutches are manufactured from heat treated alloy steel and is ideal for heavy lifting applications. Quality testing in done throughout the manufacturing process.

Designed for use with chain slings, these Clevis Chain Shortening Clutches allow you to quickly adjust the sling length by locking a chain link in place. Each unit is marked for easy identification.

Clevis shortening clutch available for 7mm/8mm, 10mm and 13mm diameter lifting chain.

To Get A Quote >

Overview of CLGR® Grade 80 Clevis Shortening Clutch

Brand	CLGR®
Standard	EN1677
Material	Super Alloy Steel
Safety Factor	4:1
Processing	Drop Forged / Quenched and Tempered
Finish	Powder Coated
Size	6mm, 7/8mm, 10mm, 13mm, 16mm, 20mm, 22mm
Tips	Color Code can be customized according to customers' requirements
Note	Never exceed working load limit

Specification of CLGR® Grade 80 Clevis Shortening Clutch

drawing-of-clgr-grade-80-clevis-shortening-clutch-china-clgr-supplier

Part No.	WEIGHT (kg)	WLL (T)	B.L (T)	A±0.3	B±2	C±0.5	D±1	E±2	H±1	L±2	φ±0.5	P±0.5	S±0.3
8CRCSC06	0.18	1.12	4.48	8	44	7.5	30	32.8	11.8	73.5	7.8	7.5	12
8CRCSC718	0.45	2	8	10.5	61.7	9.5	36	45	15.7	101	9.2	9.5	17
8CRCSC10	0.93	3.15	12.6	12.4	92	13	48	55	20	138	13.2	13	28
8CRCSC13	1.88	5.3	21.2	16	115	16.5	59	75	24.5	177	16.2	16.5	34.5
8CRCSC16	3.5	8	32	19.5	143	21	73	93	30.5	220	20	21	40
8CRCSC18/20	4.43	12.5	50	23	152	23.5	81	102	36	238	24.3	23.5	46
8CRCSC22	8.05	15	60	26	195	25.5	98	118	42	295	28.1	25.5	57.5
