CLGR® Grade 80 Master Link Assembly Forged U.S. Type

Name: CLGR® Grade 80 Master Link Assembly Forged U.S. Type
Brand: CLGR®

CLGR® Grade 80 Master Link Assembly Forged U.S. Type, also called Master Links with Sublinks G80, Oblong Master Link Sub-Assembly, Grade 80 Quad Master Link Assembly, Grade 80 Large Multi Headring.

This Master Link Assembly serves as a core rigging component, engineered to interconnect chain connectors and links for constructing composite sling systems capable of lifting heavy loads and equipment.

It comprises a fully forged master ring integrated with two or more welded sub-rings, all constructed from high-grade alloy steel.

Available in standard sizes in 3/4'', 7/8'', 1, 1-1/4'', 1-1/2'', 1-3/4'', 2, 2-1/2'', 2-3/4 ''(with custom shapes and dimensions available upon request), the assembly is designed with a 4:1 safety factor to ensure reliable performance under demanding load conditions.

To Get A Quote >

6.G80 Master Link Assembly European Type

 

Overview of CLGR® Grade 80 Master Link Assembly Forged U.S. Type

Brand	CLGR®
Standard	Conform to US Standard (ASME B30.26 )
Material	Superior Alloy Steel
Safety Factor	For chain sling: Minimum Ultimate Load is 4 times the Working Load Limit For steel rope sling: Minimum Ultimate Load is 5 times the Working Load Limit
processing	Main link: Drop Forged Sub links: Welded Quenched and Tempered
Finish	Powder Coated
Size	3/4'', 7/8'', 1, 1-1/4'', 1-1/2'', 1-3/4'', 2, 2-1/2'', 2-3/4''
Tips	Color Code: Customized according to customers’ requirements
Note	There will be pressing flat only on request. Use Only Grade 80 Attachments For Overhead Lifting

Specifications of CLGR® Grade 80 Master Link Assembly Forged U.S. Type

drawing-of-clgr-grade-80-master-link-assembly-u.s.-type-china-supplier

Part No.	SIZE (in)	WEIGHT (KG)	Chain	WLL 3 or 4 LEG-45°(T)	WLL ROPE(T)	DIMENSION(MM)
						A	B	D	a	b	d
8CRFMLAUS3/4	3/4	1.55	1/4	3.15	5.6	140±6	70±5	20±1	85±5	40±3	14±1
			5/16	4.25
8CRFMLAUS7/8	7/8	2.18	5/16	4.25	6.9	160±6	90±5	22±1	85±5	40±5	14±1
			3/8	6.7
8CRFMLAUS1/1	1	3.29	3/8	6.7	11.8	178±6	89±5	25±1	100±5	60±5	18±1
8CRFMLAUS1/4	1-1/4	7.18	1/2	11.2	17.7	222±7	110±6	32±1/-2	100±5	60±5	22±1
			5/8	17
8CRFMLAUS1-1/2	1-1/2	12.91	5/8	17	27.7	267±7	135±6	38±1/-2	180±6	100±5	30±1/-2
			3/4	23.6
8CRFMLAUS1-3/4	1-3/4	21.25	3/4	23.6	38.5	305±10	152±6	45±1/-2	180±6	100±5	32±1/-2
			7/8	31.5
8CRFMLAUS2/1	2	30.34	7/8	31.5	46.5	356±10	178±6	50±1/-2	180±6	100±5	38±1/-2
8CRFMLAUS2-1/2	2-1/2	64.4	1	45	72.6	406±10	203±7	64±3	355±8	178±6	51±1/-2
8CRFMLAUS2-3/4	2-3/4	89	11/4	67	98.4	406±10	241±7	70±3	406±8	203±6	57±1/-2

For chain sling: Minimum Ultimate Load is 4 times the Working Load Limit

For steel rope sling: Minimum Ultimate Load is 5 times the Working Load Limit
