CLGR® Grade 80 Forged Omega Link

Name: CLGR® Grade 80 Forged Omega Link
Brand: CLGR®

CLGR® Grade 80 Forged Omega Link, also known as Omega connecting links, Grade 80 Forged Omega Link.

Designed with a wide throat opening enables swift connections to diverse rigging equipment, its double retaining pin system minimizes wear.

This heavy-duty connector is certified to EN 1677 standards. It incorporates a threaded safety pin with wire-locking capability to prevent accidental disengagement and features a flat load-bearing surface to eliminate twisting during operation.

Grade 80 Omega Links are commonly used in conjunction with recessed head rings and chain for chain slings and variable type slings.

To Get A Quote >

CLGR® Grade 80 Forged Omega Link China Supplier

CLGR® Grade 80 Forged Omega Link china manufacturer

CLGR® Grade 80 Forged Omega Link china factory

 

Overview of CLGR® Grade 80 Forged Omega Link

Brand	CLGR®
Standard	EN1677
Grade	Grade 8/Grade 80
Material	Forged Super Alloy Steel
Safety Factor	4: 1
Processing	Drop Forged+Quenched and Tempered
Finish	Powder Coated
Size of Rope	6mm, 7/8mm, 10mm, 13mm, 16mm, 20mm
Tips	Color Code: Customized according to customers’ requirements

Specifications of CLGR® Grade 80 Forged Omega Link

Drawing of CLGR® Grade 80 Forged Omega Link China Supplier

Part No.	Weight (kg)	WLL (t)	B.L. (t)	A±0.5	B±2	D±1	H±1.5	L±2
8CROMEGA06	0.12	1.12	4.48	8	41	20.5	25	52
8CROMEGA7/8	0.22	2.0	8.0	10	52	23.5	35	68.5
8CROMEGA10	0.36	3.15	12.6	12	62	31.5	40.5	81
8CROMEGA13	0.71	5.3	21.2	15	81	41	54	108
8CROMEGA16	1.3	8	32	19	99	49.5	64	126
8CROMEGA20	2.2	12.5	50	23	118	58	75.6	152
