CLGR® G80 Chain Connectors (Double Steel Sleeve, Straight Pin) - Fishing Trawling China

Name: CLGR® G80 Chain Connectors (Double Steel Sleeve, Straight Pin) - Fishing Trawling China
Brand: CLGR®

The Grade 80 Chain Connectors, also known as Grade 80 Coupling Link, G80 hammerlock connecting link and G80 Component Connectors.

The G80 Connecting Links enable quick and effortless assembly without special tools. There is no recessed pin, but there are double steel sleeves.

The Grade 80 Chain Connectors are engineered for connecting hooks, master links, and other fittings to Grade 80 alloy steel chains.

Our Grade 80 chain connector is produced according to the most stringent quality control standards.

The CLGR® G80 coupling link features high strength, low weight, and durability for easy and safe handling. It comes in sizes ranging from 6 mm to 32mm.

To Get A Quote >

1.Chain Connector TL with Smooth Pin G80

CLGR® G80 Chain Connectors (Double Steel Sleeve, Straight Pin) for Sale

CLGR® G80 Chain Connectors (Double Steel Sleeve, Straight Pin) China

CLGR® G80 Chain Connectors (Double Steel Sleeve, Straight Pin) Exporter

CLGR® G80 Chain Connectors (Double Steel Sleeve, Straight Pin) Factory

CLGR® G80 Chain Connectors (Double Steel Sleeve, Straight Pin) Suppliers

 

Overview of CLGR® G80 Chain Connectors (Double steel sleeve, Straight Pin) - Fishing Trawling China

Brand	CLGR®
Size	7/8mm, 10mm, 13mm, 16mm, 18mm, 20mm, 22mm, 26mm, 32mm
Material	Superior Alloy Steel
Standard	European Type
Safety Factor	4: 1
Processing	Drop Forged / Heat Treatment
Surface Finish	Powder Coating
Note	Special specifications and marks can be made according to customer requirements.

Specifications of CLGR® G80 Chain Connectors (Double steel sleeve, Straight Pin) - Fishing Trawling China


Part No.	Size	Weight (kg)	W.L.L. (t)	B.L. (t)	A±1.5	B±1	L±2.5	K±2	H±1
8CRCN7/8	7/8	0.146	2	8	18	9.5	79.5	60.5	8.5
8CRCN10	10	0.30	3.15	12.6	25	12	90.5	68	11.5
8CRCN13	13	0.65	5.3	21.2	29	15	117	87	15
8CRCN16	16	1.15	8	32	34.5	19.8	148	108.4	19.8
8CRCN18	18	1.84	10	40	38	21	154	112	21
8CRCN20	20	2.1	12.5	50	41	24	169.5	121.5	24
8CRCN22	22	2.87	15	60	48	26	193.5	141.5	26
8CRCN26	26	4.5	21.2	84.8	57.5	31	220	158	30
8CRCN32	32	8.21	31.5	126	67	38	281	205	37

CLGR® Are Expecting Your Inquiry!

We design, manufacture and distribute products and provide services for lifting and material handling applications, the construction metal industry, the trawl industry and the yacht accessories industry.
