CLGR® Grade 100 Master Link Large Inside Length

Name: CLGR® Grade 100 Master Link Large Inside Length
Brand: CLGR®

CLGR® Grade 100 Master Link Large Inside Length, also known as G100 Enlarged Master Link, Oversized Oblong Master Link, Oblong master link, Grade 100 Oversized Masterlink.

Crafted from quenched and tempered alloy steel for superior strength, this g100 master link offers a minimum 25% higher Working Load Limit than standard G80 equivalents. Each unit is proof load tested at 2.5 times its WLL and boasts a 4:1 design factor, ensuring reliable performance for both wire rope and chain applications.

Designed with oversized masterlinks for use on large crane hooks, the G100 Master Link allows attached slings to be properly spaced for a multiple leg lift.

To Get A Quote >

CLGR® Grade 100 Master Link Large Inside Length

CLGR® Grade 100 Master Link Large Inside Length China Supplier

CLGR® Grade 100 Master Link Large Inside Length China Manufacturer

Overview of CLGR® Grade 100 Master Link Large Inside Length

Brand	CLGR®
Standard	EN1677
Material	Forged Super Alloy Steel
Safety Factor	Ultimate load is 4 times the Working Load Limit
Processing	Drop Forged + Quenched and Tempered Pressing flat only on request
Finish	Powder Coated
Size	11mm, 13mm, 17mm, 22mm, 25mm, 27mm, 32mm, 38mm, 41mm, 45mm
Tips	Color Code: Customized according to customers' requirements

Specifications of CLGR® Grade 100 Master Link Large Inside Length

drawing-of-clgr®-grade-100-master-link-large-inside-length-china-supplier

Part No.	WEIGHT (KG)	WLL 5:1 (T)	A	B	D	S × H
10CRMLLS11	0.23	1.4	100	60	11±0.5	6+0.5 × 22
10CRMLLS13	0.4	2.5	120	70	13±1	7+0.5 × 25
10CRMLLS17	0.7	4	140	80	17±1	8+0.5 × 28
10CRMLLS22	1.5	7.5	160	95	22±1	11 ± 0.5 × 35
10CRMLLS25	2.2	10	190	110	25±1	13 ± 0.5 × 43
10CRMLLS27	2.51	12.5	180	100	27+1	14 ± 0.5 × 46
10CRMLLS32	5.1	17	240	140	32+1	17 ± 0.5 × 55
10CRMLLS38	7.2	25	250	150	38+1-2	21 ± 0.5 × 65
10CRMLLS41	8.3	26.5	250	150	41+1-2	23 ± 0.5 × 73
10CRMLLS45	11.8	37	300	180	45+1-2	27 ± 0.5 × 85
