CLGR® DIN 1480 Turnbuckle Plain End

Name: CLGR® DIN 1480 Turnbuckle Plain End
Brand: CLGR®

CLGR® DIN 1480 Turnbuckle Plain End also known as DIN 1480 turnbuckle without ends, DIN 1480 Turnbuckle Plane Ends and DIN 1480 Spannschloss ohne Enden.

This turnbuckle is certified to DIN 1480 standards. It features a hot-dip galvanized steel construction for superior corrosion resistance. The plain end design allows for custom welding or fitting attachment.

This product serves structural bracing and specialized rigging applications requiring tailored solutions. It is ideal for marine and industrial environments.

To Get A Quote >

CLGR® DIN 1480 Turnbuckle Plain End China

CLGR® DIN 1480 Turnbuckle Plain End China Supplier

CLGR® DIN 1480 Turnbuckle Plain End China Manufacturer

 

Overview of CLGR® DIN 1480 Turnbuckle Plain End

Brand	CLGR®
Origin	China
Technical Notes	Straining screw To DIN1480
Material	Superior Mild Steel
Processing	Drop Forged
Finish	Zinc plated, Hot dipped galvanized
Size	M8, M10, M12, M16, M20, M24, M30 turnbuckle to DIN 1480
Important Notes	Turnbuckles are not for lifting. Only suitable for use in tension.

Tips:

Turnbuckles consist of a metal frame with right hand thread on one end and left hand thread on the other end. Used for tensioning by rotating the turnbuckle body without twisting the attached rope or cable.

Specifications of CLGR® DIN 1480 Turnbuckle Plain End

Part No.	Size	L	h	L1	L2	a	b	Φ	W.L.L.	B.L.
Part No.	Size	mm							N
CR-1480-PE-08	M8	110	8	125	70	20	11	6.5	4100	16400
CR-1480-PE-10	M10	125	9	150	85	25	13	10.5	6500	26000
CR-1480-PE-12	M12	125	11	165	85	30	16	13	9300	37200
CR-1480-PE-16	M16	170	14	250	110	40	20.5	12.5	17700	70800
CR-1480-PE-20	M20	200	17	250	110	50	27	16.5	27000	108000
CR-1480-PE-24	M24	255	21	300	153	70	45	22	39200	156800
CR-1480-PE-30	M30	255	23	349.5	150	70	45	25	62500	250000
