CLGR® Stainless Steel D Shackle Screw Pin JIS Type

Name: CLGR® Stainless Steel D Shackle Screw Pin JIS Type
Brand: CLGR®

CLGR® Stainless Steel D Shackle Screw Pin JIS Type, also knonw as JIS Type Dee Shackle.

Certified to Japanese Industrial Standards (JIS), these rated stainless steel shackles are forged from Type 304/316 stainless steel with molybdenum enhancement, delivering exceptional resistance to pitting and crevice corrosion in highly chlorinated marine environments.

Ideal for marine, offshore, and industrial rigging systems.

Available in sizes from 4mm to 38mm, these JIS-certified rated stainless steel shackles offer reliable strength and corrosion resistance for demanding operations.

Custom specifications and markings can be provided by CLGR® to meet specialized project requirements.

To Get A Quote >

Overview of CLGR® Stainless Steel D Shackle Screw Pin JIS Type

Brand	CLGR®
Standard	JIS Type
Material	AISI 304/316
Shackle Type	D Shackle
Pin Type	Screw Pin
Processing	Forged / Casting / Stamping
Finish	Highly Polishing
Size	4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 14mm, 16mm 18mm, 20mm, 22mm, 25mm, 28mm, 32mm, 36mm, 38mm
Country of Origin	China

Specifications of CLGR® Stainless Steel D Shackle Screw Pin JIS Type

drawing-stainelss-steel-d-shackle-screw-pin-jis-type-china-supplier

Part No.	Size	A	B	C	D4	E	WLL (KGS)
Part No.	mm	mm	mm	mm	mm	mm	WLL (KGS)
CRSSDSJIS04	4	14	8	8	4	4	50
CRSSDSJIS05	5	16	10	10	5	5	80
CRSSDSJIS06	6	22	12	12	6	6	100
CRSSDSJIS08	8	27	16	16	8	8	200
CRSSDSJIS10	10	31	20	20	10	10	320
CRSSDSJIS12	12	40	24	24	12	12	520
CRSSDSJIS14	14	46	28	28	14	14	700
CRSSDSJIS16	16	52	32	32	16	16	800
CRSSDSJIS18	18	58	36	36	18	18	990
CRSSDSJIS20	20	64	40	40	20	20	1100
CRSSDSJIS22	22	75	44	44	22	22	1500
CRSSDSJIS25	25	83	50	50	25	25	2100
CRSSDSJIS28	28	96	56	56	28	28	3000
CRSSDSJIS32	32	114	64	64	32	32	3500
CRSSDSJIS36	36	116	72	72	36	36	4600
CRSSDSJIS38	38	152	76	76	38	38	5000
